T commands

TRIGger:A

Sets the instrument trigger level to 50% of the minimum and maximum values of
the signal. Returns the current A trigger settings when used as a query.
The trigger level is the voltage threshold through which the trigger source signal
must pass to generate a trigger event. This command works for the following
cases: Edge Trigger (when source is not Line), Logic Trigger (when Clock
Source is not Off or Logic Pattern is Don't Care), and Pulse Width Trigger.
Group
Trigger
Syntax
TRIGger:A SETLevel
TRIGger:A?
Related commands
TRIGger:A:EDGE? on page 224, TRIGger:A:PULse? on page 231
Arguments
SETLevel sets the A trigger level to 50% of the minimum and maximum values
of the trigger source input signal. This is equivalent to pressing the front-panel
PUSH to SET to 50% button.
Examples
TRIGger:ASETLEVEL sets the A trigger level to 50% of the range of the
minimum and maximum values of the trigger input signal.
TRIGGER:A? might return a long response with A trigger parameters, some of
which could be as follows: :TRIGGER:A:MODE AUTO;TYPE EDGE;LEVEL
20.0000E-3;LEVEL:CH1 20.0000E-3;CH2 0.0000; CH3 0.0000;CH4
0.0000;:TRIGGER:A:UPPERTHRESHOLD:CH1 1.4000;CH2
800.0000E-3;CH3 8 00.0000E-3;CH4
800.0000E-3;:TRIGGER:A:LOWERTHRESHOLD:CH1 20.0000E-3;CH2
0.0000;CH3 0.0000;CH4 0.0000;:TRIGGER:A:HOLDOFF:TIME
20.0000E-9;:TRIGGER:A:EDGE:SOURCE CH1;COUPLING DC;SLOPE
RISE;:TRIGGER:A:LOGIC:CLASS SETHOLD;FUNCTION
AND;THRESHOLD: CH1 20.0000E-3;CH2 0.0000;CH3 0.0000;CH4
0.0000;:TRIGGER:A:LOGIC:INPUT:CH1 X;CH2 X;CH3 X;CH4
X;CLOCK:SOURCE NONE;EDGE.
TBS2000 Series Programmer 223
