Select:ch<X - Tektronix TBS2000 Series Programmer's Manual

S commands
SELect:CH<x>
Group
Syntax
Arguments
212
Turns the display of the channel <x> waveform on or off, where <x > is the
channel number. This command also resets the acquisition. The query returns
whether the channel is on or off but does not indicate whether it is the selected
waveform.
Vertical
SELect:CH<x> {ON|OFF|<NR1>}
SELect:CH<x>?
ON turns on the display of the specified waveform. This waveform also becomes
the selected waveform.
OFF turns off the display of the specified waveform.
<NR1> = 0 turns off the display of the specified waveform; any other value turns
on the display of the specified waveform.
Examples
SELECT:CH2 ON turns the channel 2 waveform display on, and selects channel
2.
SELECT:CH1? might return :SELECT:CH1 1 indicating that channel 1 is being
displayed.
TBS2000 Series Programmer
