Math - Tektronix TBS2000 Series Programmer's Manual

M commands

MATH?

Group
Syntax
Related commands
Returns
Examples
TBS2000 Series Programmer
This section lists commands and queries that begin with the letter M.
Returns the current math parameters. Query only.
Math
MATH?
MATH:DEFINE on page 166,
VERtical:POSition on page 169,
MATH:HORizontal:SCALe
page 167, MATH:HORizontal:UNIts
Returns the current math parameters:
The definition of the math waveform:
■
Source1 operation source2
■
Vertical scale
■
Vertical position
■
Vertical units
■
Horizontal scale
■
Horizontal position
■
Horizontal units
■
MATH? might return "CH1+CH2";2.000;0.0E+0"V",20.0000E-6;0.0E0;"s".
MATH:VERtical:SCAle
MATH:VERTical:UNIts
on page 167, MATH:HORizontal:POSition
on page 168
on page 169, MATH:
on page 170,
on
165
