Trigger:a:runt:source; Trigger:a:runt:when - Tektronix TBS2000 Series Programmer's Manual

T commands

TRIGger:A:RUNT:SOUrce

Group
Syntax
Arguments
Examples

TRIGger:A:RUNT:WHEn

Group
Syntax
Related commands
238
Sets or queries the source for the A runt trigger.
Trigger
TRIGger:A:RUNT:SOUrce {CH1|CH2|CH3|CH4}
CH1-CH4 specifies an analog input channel as the trigger source.
TRIGGER:A:RUNT:SOURCE CH4 sets channel 4 as the source for the A pulse
trigger.
TRIGGER:A:RUNT:SOURCE? might return :TRIGGER:A:RUNT:SOURCE
CH2 indicating that channel 2 is the source for the A pulse trigger.
Sets or queries the type of pulse width the trigger checks for when it detects a
runt.
Trigger
TRIGger:A:RUNT:WHEn {LESSthan|MOREthan|EQual|UNEQual|OCCURS}
TRIGger:A:RUNT:WHEn?
TRIGger:A:RUNT:WIDth on page 239
TBS2000 Series Programmer
