T commands

TRIGger:A:PULse:CLAss

Group
Syntax
Related commands
Arguments
Examples
232
Sets or queries the type of pulse on which to trigger.
Trigger
TRIGger:A:PULse:CLAss {RUNt|WIDth}
TRIGger:A:PULse:CLAss?
TRIGger:A:RUNT? on page 236,
TRIGger:A:TYPe on page 240
RUNt triggers when a pulse crosses the first preset voltage threshold but does not
cross the second preset threshold before recrossing the first.
WIDth triggers when a pulse is found that has the specified polarity and is either
inside or outside the specified time limits.
TRIGGER:A:PULSE:CLASS WIDTH specifies a width pulse for the A trigger.
TRIGGER:A:PULSE:CLASS? might return :TRIGGER:A:PULSE:CLASS
WIDTH indicating that a pulse was found that is of the specified polarity and
width.
TRIGger:A:PULSE:Width?
TBS2000 Series Programmer
on page 233,
