Ch<X>:Volts - Tektronix TBS2000 Series Programmer's Manual

Group
Syntax
Related Commands
Arguments
Examples
CH<x>:VOLts
Group
Syntax
TBS2000 Series Programmer
Vertical
CH<x>:SCAle <NR3>
CH<x>:SCAle?
CH<x>:OFFSet on page 63,
REF<x>:VERTical:SCAle?
<NR3> is the scale, in units-per-division. The value entered here is truncated to
three significant digits.
CH1:SCALE 100E-3 sets the channel 1 gain to 100 mV/div.
CH2:SCALE? might return :CH2:SCALE 1.0000, indicating that the current V/
div setting of channel 2 is 1 V/div.
Sets or queries the vertical sensitivity of the specified channel. The value of <x>
can vary from 1 through 4 depending on the instrument model.
This command is identical to the CH<x>:SCAle command and is included for
compatibility purposes. Only CH<x>:SCAle is returned in response to a CH<x>?
query.
Vertical
CH<x>:VOLts <NR3>
CH<x>:VOLts?
CH<x>:POSition on page 64,
on page 203, MATH:VERtical:SCAle
C commands
on page 169
73
