ZOOm:ZOOM1:POSition

Group
Syntax
Arguments
Examples

ZOOm:ZOOM1:SCAle

Group
Syntax
TBS2000 Series Programmer
Sets or queries the horizontal position for the specified zoom.
Zoom
ZOOm:ZOOM1:POSition <NR3>
ZOOm:ZOOM1:POSition?
<NR3> is a value from 0 to 100.00 and is the percent of the upper window that is
to the left of screen center, when the zoom factor is 1× or greater
ZOOm:ZOOM1:POSition 20 sets the percent of the upper window that is to the
left of screen center to 20%.
ZOOm:ZOOM1:POSition? might return :ZOOm:ZOOM1:POSition 25 indicating
the percent of the upper window that is to the left of the screen center is 25%.
Sets or queries the zoom horizontal scale for the specified zoom.
Zoom
ZOOm:ZOOM1:SCAle <NR3>
ZOOm:ZOOM1:SCAle?
Z commands
273
