VOYAGE DATA RECORDER
SIMPLIFIED VOYAGE DATA RECORDER
Instruction Manual
7ZPNA4013

   Also See for JRC JCY-1800

   Related Manuals for JRC JCY-1800

   Summary of Contents for JRC JCY-1800

  • Page 1

    VOYAGE DATA RECORDER SIMPLIFIED VOYAGE DATA RECORDER Maintenance Software Instruction Manual 7ZPNA4013...

  • Page 3

    JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual RECORD OF REVISIONS Description Date First edition 17-Oct.-06 DOC No. 7ZPNA4014...

  • Page 4

    JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual DOC No. 7ZPNA4014...

  • Page 5: Table Of Contents

    JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual TABLE OF CONTENTS Maintenance Software ........................1 Maintenance Software starting ..................... 3 2.1. Starting the Maintenance software .......................3 2.2. Quitting the Maintenance software.......................5 Work item selection ........................7 3.1. Home screen..............................7 3.2. Work menu..............................7 Installation, Setup and Check .......................

  • Page 6: Table Of Contents

    JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual Playback............................119 10.1. Starting ..............................119 10.2. Playback Software ...........................120 10.3. Check recorded data ..........................120 Frame Grabber Board (CKA-137) setup - FGB utility - ............121 11.1. Check the Radar image specifications .....................121 11.2. Setup & Capture............................121 11.3.

  • Page 7: Maintenance Software

    The maintenance software of JCY-1800/1850 is a PC-based application. It serves the purpose of configuring and inspecting the product at the factory. On board the ship, it helps users to install the JCY-1800/1850, settings, operational check, and to find the causes of malfunctions, if any.

  • Page 8

    1. Maintenance Software JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 9)Connection port for the Maintenance PC Connect the Maintenance PC to any port in “VDR-LAN”. -------------- ABBREVIATIONS --------------- Some of the abbreviations commonly used in this manual are: Abbreviations Name Type...

  • Page 9: Maintenance Software Starting

    2. Maintenance Software starting JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 2. Maintenance Software starting 2.1. Starting the Maintenance software 2.1.1. Starting procedure 1) To load the maintenance software, double click the “Maintenance Software” icon on a desktop. 2) The maintenance Software starts and then the Login screen will appear.

  • Page 10

    2. Maintenance Software starting JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 2.1.2.1. Selecting setup system (“Setup Equipment”) Select a setup system from VDR, S-VDR or RMS. 2.1.2.2. Entering Worker, Company and Password (“Register Information”) 1) Register Information Enter the worker information, which will be recorded onto the VDR/S-VDR.

  • Page 11: Quitting The Maintenance Software

    2. Maintenance Software starting JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 2.2. Quitting the Maintenance software 2.2.1. Check before exit Confirm the following items before logout when the installation is finished All Entry lamps shall light green in the System screen.

  • Page 12

    2. Maintenance Software starting JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual This page is intentionally left blank DOC No. 7ZPNA4014...

  • Page 13: Work Item Selection

    3. Work item selection JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 3. Work item selection 3.1. Home screen Operation button Work button 3.1.1. Selecting work item Click a work button on the Work section. The screen for the selected working item will appear.

  • Page 14

    3. Work item selection JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 3.2.2. Playback Select for checking recorded data on the VDR/S-VDR. The Playback software is loaded. 3.2.3. Option PC Select for setting up a real time monitor system. It is only an enable/disable setup of outputting a real-time monitor data.

  • Page 15: Installation, Setup And Check

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4. Installation, Setup and Check 4.1. Selecting the installation 4.1.1. Home screen Installation] To configure the VDR/S-VDR, click the [Installation] button. The “SYSTEM” screen for system (VDR/S-VDR/RMS) selected at log-in will appear.

  • Page 16

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual ● JCY-1850 ● Difference between the JCY-1800 and the KCY-1850 • The number of sensor connection channels •The capsule model DOC No. 7ZPNA4014...

  • Page 17

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.1.2. Operating procedure for installation Set up and check the VDR/S-VDR on the “SYSTEM” screen as following procedure. Step Item Operation Contents The Maintenance software receives a system configuration data from the RCU.

  • Page 18: Receiving A Configuration Data And Starting A Diagnosis Function

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.2. Receiving a configuration data and starting a diagnosis function 4.2.1. Receiving a configuration data of RCU Start a maintenance operation from receiving a configuration data. 1) Click the [Receive] button.

  • Page 19: Sensor Connection Setup

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.3. Sensor connection setup 4.3.1. Setting connection Enable / Disable of each sensor connection can be set up. 1) Each channel Enter a check mark into the check box of connected CH.

  • Page 20

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.3.3. Selecting a recording data Select the connection equipment and recording data according to the following procedure. The initial value for receiving the data of the equipment chosen is set up automatically on the detail setting window.

  • Page 21

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.3.3.2. When setting data is changed • In case of changing the detail setup data registered: Choose the “No” (Default) of radio button and click the [Next] button. • In case of changing the selected “Recording item” and selected “Equipment”: Choose the “Yes”...

  • Page 22

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual Selection table Recording item Equipment Recording data Sentence ID Date and Time ??ZDA ??RMC Date & Time/Ship's GPS(Main) Position Ship's Position ??GGA ??GLL ??GNS ??RMCV Local Geodetic Datum(DTM) ??DTM...

  • Page 23

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual Recording item Equipment Recording data Sentence ID Option Unit DSC (CH13) Dry Contact Data (CH13) ????? DSC (CH14) Dry Contact Data (CH14) ????? DSC (CH15) Dry Contact Data (CH15)

  • Page 24

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.3.4. Detail setup window of sensor (standard) 4.3.4.1. Identification TAB screen Set an identification data of connected equipment 1) Equipment Enter the name of the connecting equipment. (GPS, Echo sounder, etc.) * When except “Other”...

  • Page 25

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.3.4.2. Data TAB screen Check the entry data, when initial values are entered as record item selected in pre-procedure. Change entry data, when required. Enter a setup data when “Other” is selected as record item in pre-procedure.

  • Page 26

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.3.4.2.2. Communication parameters and Sentence format Set the communication parameter and Set the sentence format. Once the type is selected, this parameter is automatically set by default. There is no need to change this value.

  • Page 27

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.3.4.2.3. Recording data Whether a sentence is recorded in the VDR/S-VDR is determined by the sentence ID. Any sentence of which ID is different from the specified sentence ID is discarded and is not recorded in the VDR/S-VDR.

  • Page 28

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.3.4.3. Checking setup data Confirm that there is no blank in setting data. Defect in setting entry (Model, Serial number, etc.) as warning can be displayed to the “Entry” lamp.

  • Page 29

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.3.4.6. Result of diagnosis Confirm that The VDR/S-VDR receives a recording data. As for the diagnostic result of the [Sensor] section, a result is displayed to the "Diagnosis" lamp at setting.

  • Page 30

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.3.5. Detail setup window of GPS (sensor section) Setup screen of GPS is a special screen for connecting two GPS. Sub GPS setting is required when connecting two GPS to one port via a switcher.

  • Page 31

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.3.5.2. GPS Selection TAB screen Set up the “GPS selection” when the “GPS (main+sub)” is selected as a connection equipment. 1) Switch position Select the logic of dry contact signal which is outputted by a GPS switcher.

  • Page 32: Nsk Connection Setup

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.4. NSK connection setup 4.4.1. Setting connection CH33 and CH34 of a Sensor section are the connection CH with NSK. Enable / Disable of heading data connection can be set up to CH33.

  • Page 33

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.4.3. Detail setup window of Heading data (CH33) 4.4.3.1. Identification TAB screen Set an identification data of connected equipment which output a Synchro signal or a step signal as heading data.

  • Page 34

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.4.3.2. Heading TAB screen 4.4.3.2.1. Signal Type Select Synchro or Step as signal type. 4.4.3.2.2. Ratio Select ratio in 1, 36, 90, 180 or 360 deg. 4.4.3.2.3. Gray Code Select Order Direction or Reverse Direction as rotation direction.

  • Page 35

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.4.3.2.5. Heading Data Even if it does not input the initial value of a heading from the OPU, the initial value of a heading can be inputted from on the Heading TAB screen.

  • Page 36

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.4.4. Detail setup window of Speed data (CH34) 4.4.4.1. Identification TAB screen Set an identification data of connected equipment which output a Pulse signal as ship’s speed data. 1) Equipment Enter the name of the connecting equipment.

  • Page 37: Option Unit (nct-72/63) Connection Setup

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.5. Option unit (NCT-72/63) connection setup In order to record a dry contact signal and an analog signal by the VDR/S-VDR, the Digital Signal Converter (DSC: NCT-72/63) of an option unit is connected to the VDR/S-VDR. Set up the DSC in the following procedure.

  • Page 38

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.5.3. Selecting a recording data Select the option unit (NCT-72/63) and recording data according to the following procedure. The initial value for receiving the data of the option unit (NCT-72/63) is set up automatically on the detail setting window.

  • Page 39

    The inside of a parenthesis shows Connection CH. 2) Model Enter the model name of the connecting equipment. (NCT-72/63) 3) Manufacturer Enter the name of the manufacturer of the connecting equipment. (JRC) 4) Serial No. Enter the serial number of the connecting equipment. DOC No. 7ZPNA4014...

  • Page 40

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.5.4.2. Data TAB screen According to selection of "DSC" or "DSC+A/D", an appropriate data is entered automatically. ● DSC+A/D ● DSC 4.5.4.3. Transmitting a setup data for NCT-72/63 connection Transmit a setup data for NCT-72/63 connection to the RCU after entering all data on “Identification”...

  • Page 41

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.5.5. Detail setup window of dry contact (Dry Contact TAB screen) It is a screen for transmitting and receiving the configuration file of NCT-72/63. 4.5.5.1. Program Version Display of NCT-72/63 Click the [Version] button.

  • Page 42

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.5.5.4. Setup screen of sentence data (alarm, door, etc.) Dry contact data, such as alarm and a door, should be changed into a NMEA sentence data. The screen for creating conversion table file will appear.

  • Page 43

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual ● State of a dry contact signal The condition of the equipment shown by OPEN/CLOSE of a dry contact signal is set up. 1) Alarm Select the inputting dry contact state (OPEN/CLOSE) when the connected equipment is a normal state.

  • Page 44

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual * A selection setup from a tree structure The tree structure displayed on a left screen is the dry contact signal which can be registered. Sentence data can be set up in double-clicking the data of tree structure.

  • Page 45

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 3) Registering sentence data Click the [SET] button after all categories are selected and comment is inputted. The sentence according to the contents of selection is created, and it is added to a setup file.

  • Page 46

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.5.5.5. Registration screen of sentence data for engine telegraph This screen is an exclusive screen for an engine telegraph setup. 4.5.5.5.1. Screen change Click an “Engine Telegraph” from “Type” menu.

  • Page 47

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 2) Selecting connected dry contact signals On a selecting menu, all the signals of an engine telegraph position can be registered, the connected dry contact signal is necessary to select.

  • Page 48

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 2) Enable setting Setup procedure is the same as “Engine telegraph position”. 3) Disable setting Select the “Other”. 4.5.5.5.5. Order or Response (Status) Select the sentence type (Order / Response) of engine telegraph signals.

  • Page 49

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.5.5.6. All setup is completed The configuration file created to NCT-72/63 is transmitted when all setup is completed. 1) Transmit the configuration file. Click the [Send] button. 2) The setup screen is completed and it returns to the Transmit/Receive screen of a configuration file.

  • Page 50

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.5.5.8. Real time monitor of dry contact sentence Check that registration and electric wiring of a dry contact signal are correct by the real-time monitor. 4.5.5.8.1. Real Time Monitor The NMEA sentence can be monitored by the real time monitor on the setting screen.

  • Page 51

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.5.5.9. Diagnostic result of dry contact signal Enter a diagnostic result manually. 1) Dialog for entering a diagnostic result Click the [DSC Check] button. The dialog for entering a diagnostic result will appear.

  • Page 52

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.5.6. Detail setup window of analog signal (A/D TAB screen) It is a screen for setup analog signal. The data which is inputted on the setup screen of each channel are displayed on this screen.

  • Page 53

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.5.6.2.1. Identification of Analog signal output Equipment Set a information data of connected Analog signal output equipment. 1) Equipment Enter the name of the connecting equipment. 2) Model Enter the model name of the connecting equipment.

  • Page 54

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.5.6.2.3. Calculating a coefficient Set up the coefficient of the formula this converts the output value (%) of the ACB into a real value (displayed on a equipment). 1) Selecting CH Select an analog channel to set up.

  • Page 55

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.5.6.2.4. Setting of Analog signal information The specification and information of the analog signal are set up. 1) Data unit Select the data unit of receiving data. Unit -...

  • Page 56

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.5.6.4. Diagnostic result of analog signal Enter a diagnostic result manually. 1) Dialog for entering a diagnostic result Click the [A/D Check] button. The dialog for entering a diagnostic result will appear.

  • Page 57

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.5.6.5. 4.5.6.6. Analog Signal Converting Board (CEF-60) setup The parameter setup of the following input signal is set up by the strap on PCB. Other setup items are set up with maintenance software.

  • Page 58: Radar Connection Setup

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.6. Radar connection setup 4.6.1. Setting connection Enable / Disable of Radar connection and the FGB can be set up. 1) Each channel Enter a check mark into the check box of “Sub radar” in case of connecting two Radar units.

  • Page 59

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.6.3. Detail setup window of Radar 4.6.3.1. Identification TAB screen 4.6.3.1.1. Identification data of Radar Set an identification data of connected Radar. 1) Model Enter the model name of the connecting equipment.

  • Page 60

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.6.3.1.2. Setup file of FGB The setup file of FGB can be downloaded and uploaded. The setup file of FGB is saved in the “FGB_Util¥CKA137-JCY1800” folder under an install folder of maintenance software.

  • Page 61

    Select the “Dry contact”, when recording channel is switched by dry contact signals outputted from a switcher. 2) NMEA Select the “NMEA”, when recording channel is switched by the PJRC sentence outputted from the JRC radar. 3) None (Auto) Select the “None”, when the switching signal is not connected.

  • Page 62

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.6.3.3. Real Time Monitor Monitor the Radar Image which is recorded in the VDR/S-VDR at real time to check the operation is working correctly. 1) Selecting the monitor CH The image received by CH1 is displayed on TAB “Image 1”...

  • Page 63

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual ● Judge an image quality. Click the radio button of judgment result. Enter a comment at NG. * A click of the [Help] button displays advice of an Image quality judging.

  • Page 64

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.6.3.5. Transmitting setup data Transmit the setup data to the RCU. • Transmit Click the [SET] button. • Cancel Click the [Close] button. 4.6.3.6. Result of diagnosis As for the diagnostic result of the [Radar] section, a result is displayed to the "Diagnosis" lamp.

  • Page 65: Microphone Connection Setup

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.7. Microphone connection setup 4.7.1. Setting connection Enable / Disable of each Microphone connection can be set up. 1) Each channel Enter a check mark into the check box of connected CH.

  • Page 66

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.7.3. Detail setup window of Microphone 4.7.3.1. Identification TAB screen Set an identification data of connected Microphone. 1) Type Select an indoor type or a waterproof type. 2) Place Enter the position installed a microphone.

  • Page 67

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.7.3.2. Real Time Monitor Monitor the Audio of Microphones which is recorded in the VDR/S-VDR at real time to check the operation is working correctly. Caution: Audio data is mixed by three input signal from each Microphone. For checking that each Microphone is correctly working, it is necessary to connect only one Microphone to monitor.

  • Page 68

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.7.3.3. Checking setup data Confirm that there is no blank in setting data. 1) Entry lamp Defect in setting entry (Model, Serial number, etc.) as warning can be displayed to the “Entry”...

  • Page 69

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.7.3.5. Result of diagnosis As for the diagnostic result of the [Microphone] section, a result is displayed to the "Diagnosis" lamp. ● (Green): Result of diagnosis is good. ●...

  • Page 70: Vhf Connection Setup

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.8. VHF connection setup 4.8.1. Setting connection Enable / Disable of each VHF transceiver connection can be set up. 1) Each channel Enter a check mark into the check box of connected CH.

  • Page 71

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.8.3.1. Identification TAB screen Set an identification data of connected VHF transceiver. 1) Model Enter the model name of the connecting equipment. 2) Manufacturer Enter the name of the manufacturer of the connecting equipment.

  • Page 72

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.8.3.3. Checking setup data Confirm that there is no blank in setting data. 1) Entry lamp Defect in setting entry (Model, Serial number, etc.) as warning can be displayed to the “Entry”...

  • Page 73: Vdr/s-vdr System Setup

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.9. VDR/S-VDR system setup 4.9.1. Starting detail setup The detailed setup window of VDR/S-VDR is displayed. Click the [Detail] button on VDR section, a detail setup window is displayed.

  • Page 74

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.9.2.1. Identification TAB screen 4.9.2.1.1. Ship’s Identification Enter the ship’s identification data. 1) Ship’s name Enter the ship’s name. 2) IMO ID number. Enter the IMO ID number. 4.9.2.1.2. Q’ty These information are used with the Playback software.

  • Page 75

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.9.2.2. Register Information TAB screen 4.9.2.2.1. Register information Registrant information entered on the Log-in screen is displayed. Registrant information which is stored in the RCU is displayed at receiving the configuration data.

  • Page 76

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.9.2.3. Maintenance TAB screen 4.9.2.3.1. Battery The expiry date of the battery is displayed. Enter new expiry date of the battery, when you exchange a battery. The expiry date of a battery is indicated on the battery label.

  • Page 77

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.9.2.3.3. Beacon of capsule Enter an information data of Beacon. 1) Serial No. Enter the serial number of the capsule. 2) Next Replacement The expiry date of the battery in the beacon of capsule is displayed.

  • Page 78

    JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.9.2.4. Software Version TAB screen 4.9.2.4.1. System Version The software version of JCY-1800/1850 system is displayed. 4.9.2.4.2. Maintenance number The Maintenance numbers of each unit (PCB) are displayed. Report all Maintenance numbers for repairing. DOC No. 7ZPNA4014...

  • Page 79

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.9.2.5. PCB ID TAB screen 4.9.2.5.1. PCB Serial No. The serial numbers of each PCB are displayed. In replacing a PCB, enter a serial number on a new PCB which is installed into a unit.

  • Page 80

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.9.2.6. Option TAB screen 4.9.2.6.1. Enter a check mark into the “NSK” check box when a Heading data or ship’s speed data is recorded via NSK in VDR/S-VDR. 1) Setting •...

  • Page 81

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.9.2.7. PI-1 to 3 TAB screen 4.9.2.7.1. Internal Dry Contact General dry contact signals can be inputted, and general dry contact signal data can be recorded as NMEA sentence data.

  • Page 82

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.9.2.8. Checking setup data Confirm that there is no blank in setting data. 1) Entry lamp Defect in setting entry as warning can be displayed to the “Entry” lamp.

  • Page 83: Capsule Setup

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.10. Capsule setup 4.10.1. Starting detail setup The detailed setup window of Capsule is displayed. Click the [Detail] button on Capsule section, a detail setup window is displayed. 4.10.2. Detail setup window of capsule 4.10.2.1.

  • Page 84

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.10.2.2. Checking setup data Confirm that there is no blank in setting data. 1) Entry lamp Defect in setting entry as warning can be displayed to the “Entry” lamp.

  • Page 85: System Configuration File

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 4.11. System Configuration File 4.11.1. File open The VDR/S-VDR can be set up by opening a configuration file. (Not Receiving) Click the “Open” in the “File” menu and select the configuration file to open.

  • Page 86

    4. Installation, Setup and Check JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual This page is intentionally left blank DOC No. 7ZPNA4014...

  • Page 87: System Screen

    5. SYSTEM Screen JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 5. SYSTEM Screen On a SYSTEM screen, a connection setup can be entered, and the operating state of a VDR/S-VDR system and the condition (good/no) of a received signal can be checked.

  • Page 88: Common Button On The System Screen

    5. SYSTEM Screen JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 5.1. Common button on the SYSTEM screen How to operate the function of the common button on the SYSTEM screen 1) [Receive] button The Maintenance software receives the system configuration data of RCU Click the [Receive] button, progress of data reception is displayed on the progress bar arranged at the lower of the screen.

  • Page 89: Sensor Section

    5. SYSTEM Screen JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 6) [Alarm Mute] button The [Alarm Mute] button is used to prohibit the ALARM BUZZER of OPU. Click the [Alarm Mute] button. Even if an error occurs during a maintenance communication link, an ALARAM BUZZER does not sound.

  • Page 90: Modified Setup Indicating

    5. SYSTEM Screen JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 5.3. Modified setup indicating On a SYSTEM screen, when the setup data is modified, the modified item is indicated by red. Furthermore, the button which should be operated to activate modification is indicated by red.

  • Page 91: Diagnosis Function

    5. SYSTEM Screen JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 5.4. Diagnosis function 5.4.1. Diagnosis button The receive data from a connection equipment and the operating state of the VDR/S-VDR are diagnosed, and the diagnostic result is displayed on a lamp.

  • Page 92: System Status Window

    5. SYSTEM Screen JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 5.5. System status window The System status data of each section can be displayed The system status shows the detail information of an error factor. * Effective section: VDR, Radar, Microphone, VHF, Capsule * Sensor section shows a recording sentence ID list.

  • Page 93

    5. SYSTEM Screen JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 3) Sensor section Click the [Sensor] button positioned upper left of the sensor section. The recording sentence ID list will appear. DOC No. 7ZPNA4014...

  • Page 94: Operation Button

    5. SYSTEM Screen JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 5.6. Operation button Click a operation button arranged on the left of the SYSTEM screen. A operation window or application which selected is activated. Button Operation Log in Return the Log in screen 2.1.

  • Page 95: Event Monitor

    6. EVENT Monitor JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 6. EVENT Monitor Monitor the operation event of VDR/S-VDR to check that VDR/S-VDR system is working correctly. The EVENT monitor can display a receiving EVENT data from the VDR/S-VDR. Furthermore, the EVENT monitor can display EVENT Log files in the VDR/S-VDR additionally.

  • Page 96

    6. EVENT Monitor JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual DOC No. 7ZPNA4014...

  • Page 97: Modification Of Event List Display

    6. EVENT Monitor JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 6.2. Modification of EVENT list display Old event data can be displayed by downloading event log files from the RCU. The event log files consist of event data recorded on the CF card by the RCU.

  • Page 98

    6. EVENT Monitor JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 6.2.3. Extract event data EVENT to display can be extracted per category. • The extracted event data list is displayed in a new Window. • Kind of category: NMEA, FGB (Radar image), Audio, Capsule, Card, System •...

  • Page 99

    6. EVENT Monitor JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 6.2.4. EVENT sort The EVENT monitor supports a sort function. 1) Click the each field title. It is displayed the sorted event list. 2) EVENT which received during the sort display is added to a head of list.

  • Page 100: Event Log File Open

    6. EVENT Monitor JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 6.3. EVENT log file open The EVENT log file recorded by the RCU and the file saved by the EVENT monitor can be opened. • The saved event log files in the CF card •...

  • Page 101: Event Monitor Record

    6. EVENT Monitor JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 6.5. EVENT monitor record The receiving EVENT data can be recorded as a file. 1) Record start Click the [Record Start] button. Select a save folder on the File dialog. A file name means recording start time This button display changes to [Record Stop].

  • Page 102

    6. EVENT Monitor JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual This page is intentionally left blank DOC No. 7ZPNA4014...

  • Page 103: Real Time Monitor (menu)

    7. Real time Monitor (Menu) JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 7. Real time Monitor (Menu) Although NMEA data, image data and audio data can be monitored on each "Detail screen" of a SYSTEM screen, real time monitor to which the facility was extended can be started from the menu.

  • Page 104: Nmea Monitor

    7. Real time Monitor (Menu) JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 7.2. NMEA monitor Monitor the NMEA sentence data, and check the sentence specified by the installation drawings is collected correctly. 7.2.1. Monitor conditions setup Set up the monitor conditions.

  • Page 105

    7. Real time Monitor (Menu) JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 7.2.1.2. Selecting the monitor data type Click the radio button of data type (“RCV data”/”REC data”) to monitor. ● “RCV data”: Monitors all receiving data from selected channel. The sentence data which is not recorded by the VDR/S-VDR is also displayed.

  • Page 106

    7. Real time Monitor (Menu) JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 7.2.4. Event clear The monitoring window can be cleared. Click the [Clear] button. 7.2.5. File save Monitor data can be saved in the file. 1) Select a saving folder Click the [Browse] button to select the saving folder.

  • Page 107: Audio Monitor

    7. Real time Monitor (Menu) JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 7.3. Audio monitor Monitor the Audio data which is recorded in the ARB to check the operation is working correctly. Play button Stop button Volume 7.3.1. Selecting the monitor channel Click the selection button of CH to monitor.

  • Page 108: Radar Monitor

    7. Real time Monitor (Menu) JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 7.4. Radar monitor Monitor the Radar Image Monitor which is recorded in the FGB to check the operation is working correctly. 7.4.1. Operation It is not necessary to operate it since the monitor is started automatically.

  • Page 109: Dry Contact Monitor

    7. Real time Monitor (Menu) JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 7.5. Dry Contact monitor Monitor the dry contact data which is collected in the NCT-72/63, and check a dry contact state specified by installation drawings is collected correctly. Be sure to check the collecting data of all channels.

  • Page 110

    7. Real time Monitor (Menu) JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 7.5.2.1. Dry contact of Alarm A dry contact state is displayed with a lamp icon. ▪ Green lamp: A target status is normal. ▪ Red lamp: A target status is abnormal.

  • Page 111

    7. Real time Monitor (Menu) JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 7.5.3. Clear the result of monitor The result of monitor can be cleared. Click the [Clear] button. 7.5.4. The wrong result of monitor When the monitoring dry contact state shows contrary information to the outputting information of the connected equipment, correct the setting data of the NCT-72/63.

  • Page 112

    7. Real time Monitor (Menu) JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual This page is intentionally left blank DOC No. 7ZPNA4014...

  • Page 113: System Status Display

    8. System Status Display JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 8. System Status Display The operating state of VDR/S-VDR is displayed in detail. Check a detailed factor of error by this screen. Although the system state is displayed in each category unit in the SYSTEM screen, all items can be displayed on this system status screen.

  • Page 114

    8. System Status Display JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 8.2.2. Record Control 8.2.3. ROM Checksum DOC No. 7ZPNA4014...

  • Page 115: Start System Status Display

    8. System Status Display JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 8.3. Start System status display 8.3.1. When the diagnostic function is started Since the diagnostic result is displayed, it is not necessary to operate it. The [Diagnosis] button is a green display.

  • Page 116: System Status Data File

    8. System Status Display JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 8.5. System status data file If the system configuration file (McbDataInfo.dat) saved at the report folder created after the completion of installation is opened, the system state file (Status.dat) saved at the same folder can be opened automatically, and the diagnostic result at that time can be displayed.

  • Page 117: Functions Of Menu

    9. Functions of Menu JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 9. Functions of Menu The serviceable function which can be operated from the menu is explained. 9.1. Menu table Refer to a remark column. Mark (►) shows a function which is explained in this clause.

  • Page 118: Control

    9. Functions of Menu JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 9.2. Control The VDR/S-VDR can be controlled by the Maintenance software. 9.2.1. Starting Click the “Control” of menu. 9.2.2. Reboot system The MCB (VDR/S-VDR) and RMB (RMS) can be rebooted with remote control.

  • Page 119

    9. Functions of Menu JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 9.2.3. FGB maintenance mode The MCB controls the FGB to record a image file during a VDR/S-VDR operating. The FGB can not take maintenance while the MCB is communicating to the FGB with Ethernet link.

  • Page 120

    9. Functions of Menu JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 9.2.6. Request Unit Mode and Function The operation mode and function status of the MCB or the RMB can be displayed. 1) Click the target unit button. ([MCB] button, [RMB] button) •...

  • Page 121: Convert (recorded Sensor Data To Text File)

    9. Functions of Menu JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 9.3. Convert (Recorded sensor data to text file) The recorded NMEA sentence data can be converted to a text file. The NMEA sentence data is files saved in the CF card or downloaded from the capsule.

  • Page 122: Config (extract A Setup File From A Sysinfo.dat File)

    9. Functions of Menu JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 9.4. Config (Extract a setup file from a SysInfo.dat file) A setup file of each unit (MCB, FGB, etc.) is extracted from a “SysInfo.dat” file saved in the CF card or the capsule.

  • Page 123: Error Code List

    9. Functions of Menu JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 9.5. Error Code List The cause and its countermeasure of the error code displayed on the OPU can be displayed. 9.5.1. Starting 1) Click the "Error Code List" from the "Help" pull down menu on the system screen.

  • Page 124: Software Version Display

    9. Functions of Menu JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 9.6. Software Version display The software version display Window is opened. 9.6.1. Starting 1) Click the “Software Version” from “Help” menu. 9.6.2. Software version display window DOC No. 7ZPNA4014...

  • Page 125: Playback

    10. Playback JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 10. Playback Check that Installation, Setup, and Functions of the VDR/S-VDR are completed appropriately by playback data of the capsule and the CF card. 10.1. Starting 10.1.1. Start on the SYSTEM screen Click the [Playback] button on the SYSTEM screen.

  • Page 126: Playback Software

    10. Playback JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 10.2. Playback Software The Launcher of Playback software starts. The recorded data of VDR/S-VDR are saved on the Capsule and the CF card. It is necessary to play back and check these both.

  • Page 127: Frame Grabber Board (cka-137) Setup - Fgb Utility

    11. Frame Grabber Board (CKA-137) setup - FGB utility - JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual - FGB utility - Frame Grabber Board (CKA-137) setup “FGB_Utility” software is useful for setup and tuning the Frame Grabber Board CKA-129/CKA-137. The setup menu contain that the capture setup file and other file set the board.

  • Page 128

    11. Frame Grabber Board (CKA-137) setup - FGB utility - JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 11.2.2. Select the channel for tuning a) Click the icon. If tuning the channel 2, click the icon. And if “Ch2.txt NG” message appears, set the channel 2 capture setting using [Ch 2 capture setting] menu, refer to next section.

  • Page 129

    11. Frame Grabber Board (CKA-137) setup - FGB utility - JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual Measured value Sync Activity ch 1 Sync Activity ch 2 V sync polarity H sync polarity V sync frequency H sync frequency: Total line number...

  • Page 130

    11. Frame Grabber Board (CKA-137) setup - FGB utility - JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 11.2.4. Set the capture setup a) Click the [Setup(S)] -> [Ch 1 capture setting] menu. (If set the channel 2 capture setup, click the [Ch 2 capture setting] menu.) File select window appears.

  • Page 131

    11. Frame Grabber Board (CKA-137) setup - FGB utility - JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual d) Click the [Open] button on file select window. The following message appears. If "Capture1.txt write NG" message appears, retry to step a) to d).

  • Page 132: Tuning

    11. Frame Grabber Board (CKA-137) setup - FGB utility - JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 11.3. Tuning Tune in the following order. 1) Sync polarity tuning 2) Horizontal position tuning 3) Vertical position tuning 4) Sampling Phase tuning 11.3.1. Sync polarity tuning a) Click [Information (I)] ->...

  • Page 133

    11. Frame Grabber Board (CKA-137) setup - FGB utility - JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual d) Click the [Tuning (T)] -> [H Sync polarity reverse] The following message appears. e) Click the [OK] button. Automatically reverse the H sync polarity, and capture the image. And the following message appears.

  • Page 134

    11. Frame Grabber Board (CKA-137) setup - FGB utility - JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 11.3.2. Horizontal position tuning If the captured image shifted horizontal, tune the Horizontal position. If the captured image large shifted, tune by the mouse. If the small shifted, tune by the manual.

  • Page 135

    11. Frame Grabber Board (CKA-137) setup - FGB utility - JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual e) If execute horizontal position tuning at this point, click the [Yes] button. If retry to point the image, click the [No] button and click the horizontal edge of the image.

  • Page 136

    11. Frame Grabber Board (CKA-137) setup - FGB utility - JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 11.3.3.1. Sampling Phase tuning If the captured image out of focus, tune the sampling phase. Normally, do the Phase AUTO turning. Phase AUTO tuning execute on still image, so stop the Radar transmit.

  • Page 137: Option System Setup

    12. Option System setup JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 12. Option System setup The data output conditions for the real-time monitor system are set up. 12.1. Starting 12.1.1. Start on the SYSTEM screen When the “SYSTEM” screen is displayed, move to the “HOME” screen.

  • Page 138: Setup Procedure

    12. Option System setup JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 12.2. Setup procedure 1) Receive a setup data. Click the [Receive] button. 2) Input the setup data Select the output data to the real-time monitor. 3) Transmit the setup data Click the [Set] button.

  • Page 139: Report

    13. Report JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 13. Report When installation is completed, Create a result report using this function. 13.1. Starting 1) Click the [Report] button on the SYSTEM screen. “Report” screen will appear. 13.1.1. Report The report folder is created automatically. The report folder includes a setup file and so on as installation report.

  • Page 140

    13. Report JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual This page is intentionally left blank DOC No. 7ZPNA4014...

  • Page 141: Program Update

    14. Program update JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 14. Program update Update the program of MCB, ARB RMB and FGB in the RCU. 14.1. Program update of MCB, ARB and RMB Update the program of MCB (CDJ-2304), ARB (CHA-387) and RMB (CDK-287).

  • Page 142

    14. Program update JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 14.1.2. Select an update program (1. Program) 1) Select a program Select an update program with a program radio button. 2) Check a version of program Check a version number of present program.

  • Page 143: Program Update Of Fgb

    14. Program update JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 14.2. Program update of FGB Update the program of FGB (CKA-137). 14.2.1. Preparation for FGB update The application for update starts from the “System” menu on the “System” screen. When the "Home" screen is displayed, click the [Installation] button to move to the "System" screen.

  • Page 144

    14. Program update JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 3)Back the root menu Click the [Back] button of IE, and a display screen will be back to the root menu. * Do not click the [renew] button. 14.2.2. Starting the FGB Update application Start the FGB update application.

  • Page 145: Playback Software Setup

    15. Playback Software setup JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 15. Playback Software setup 15.1. How to play back downloaded data from the Capsule with Ethernet Show the flow from setup to playback below. Stop recording to capsule. Download data from VDR/S-VDR by Download software.

  • Page 146

    15. Playback Software setup JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual (3) Select a save place with Folder selection button, and then select a playlist. When download is started, playlists (from playlist1 to playlist10) are created automatically under the save place.

  • Page 147

    15. Playback Software setup JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 15.1.2. Set information required for playback with Setup software (1) Click the [SETUP] button, and start the Setup software. (2) The Login screens is indicated, and click the [OK] button after confirming that user is selected in the Operator block.

  • Page 148

    15. Playback Software setup JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 15.1.3. Start the Playback Software (1) Click the [PLAYBACK] button from Launcher menu, and start the Playback software. DOC No. 7ZPNA4014...

  • Page 149: How To Play Back Cf Card Data In Vdr/s-vdr

    15. Playback Software setup JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 15.2. How to play back CF card data in VDR/S-VDR In order to play back record data of CF card, it is necessary to create a playback folder in the computer of use advance, and to copy the data.

  • Page 150

    15. Playback Software setup JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual (3) Eject a CF card from the VDR/S-VDR, and insert it into the CF card slot of used PC. Then, to import VDR/S-VDR configuration data, select the following file in the CF card and click the [Import] button.

  • Page 151

    15. Playback Software setup JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 15.2.3. Copy a record data of CF card (1) Click the [PLAYBACK] button, and start the Playback software. (2) Playback screen is indicated. (3) Click the [Playlist] button on the Playback Operation Panel.

  • Page 152: How To Exit The Playback Software

    15. Playback Software setup JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual (5) Select a playlist in the Copy place, and click the [Copy] button. (6) Select radio button of the playlist copied CF card data, and click the [OK] button. (7) The setup is completion above, and it is possible to play back with the [Playback] button.

  • Page 153: Installation

    JCY-1800/1850 VDR/S-VDR Maintenance Software Instruction Manual 16. Installation Installation procedure of the maintenance software for JCY-1800 / 1850 16.1. Uninstall the old version If the old version is installed, install after deleting the old version from the”Control Panel” -”Add/remove Programs” of Windows.

  • Page 154

    5) Start installation Click the [Install] button to start the installation. Click the [Finish] button. 9) Installing completion The shortcut for the “Maintenance Software” of the JCY-1800 / 1850 will be placed on the desktop. Double-click it to start. DOC No. 7ZPNA4014...

This manual also for:

Jcy-1850

Comments to this Manuals

Symbols: 0
Latest comments:
