Control Techniques Commander SE Advanced User's Manual page 87

11.42
0 no
1 rEAd When this is set and the user performs a drive reset by pressing the STOP/RESET key
2 Prog When this is set and the user performs a drive reset by pressing the STOP/RESET
3 AutO When this is set and the user performs a parameter save by pressing the mode button
4 boot
NOTE
Alternatives to pressing the STOP/RESET when in rEAd or Prog modes:
• Set parameter 10.33 to a 1 via serial communications
• Set parameter 10.38 to 100 via serial communications
• Toggle a terminal programmed as a reset terminal
NOTE
Any parameter values that have been changed via serial communications but not stored in the drives EEPROM
memory will not be stored in the Quickey
When the drive parameters are stored to the Quickey, if the current mode is rEAd or Prog, it is stored in the Quickey as no. If
the current mode is AutO or boot, these are stored as AutO or boot.
NOTE
The Quickey memory contains drive size specific information. If the contents of the Quickey are copied to a drive of
a different rating to that previously programmed, the drive will trip with the code C.rtg. This signifies that all of the
parameters apart from the drive rating specific parameters have been copied from the Quickey.
NOTE
The Quickey should only be installed or removed when power to the drive has been switched off.
Different drive ratings
The cloning key can be used to copy parameters between drives with different ratings but certain rating dependant
parameters are not copied to the cloned drive, but are still stored within the cloning key.
Drive Rating has changed
Parameter
02.08
04.07
04.08
05.07
06.06
05.09
05.17
05.23
21.07
21.09
21.12
21.13
In the event that the ratings are different the parameters are firstly written to the drive and then the drive will trip with C.rtg.
Commander SE Advanced User Guide
Issue Number: 4
Parameter cloning
0 ~ 4 0
Do nothing
while the drive is disabled (ih), tripped (tr) or on stand-by (rd), the Quickey contents will
be copied to the drive and parameter 11.42 reset to no (0). These parameters are then
saved automatically by the drive.
key, the Quickey contents will be updated with the current drive EEPROM memory
parameter settings. Parameter 11.42 is also reset to no (0).
after adjusting a parameter value, the drives current EEPROM memory parameter
settings are saved in the Quickey.
When this is set, it provides exactly the same functionality as Auto but in addition it will
overwrite the drives EEPROM memory parameter settings with the Quickey parameter
settings when the drive is powered up. These parameters are then automatically saved
by the drive. This mode provides a very fast and efficient way of re-programming a
number of drives.
Description
Standard ramp voltage
Current Limit
Torque Reference
Motor 1 rated current
Injection braking level
Motor 1 rated voltage
Motor 1 stator resistance
Motor 1 voltage offset
Motor 2 rated current
Motor 2 rated voltage
Motor 2 stator resistance
Motor 2 voltage offset
RW Uni Txt R
