Menu 8: Digital inputs and outputs

Parameter
8.01 Digital input / output 1 (Terminal 8)
8.02 Digital input 2 (Terminal 9)
8.03 Digital input 3 (Terminal 10)
8.04 Digital input 4 (Terminal 11)
8.05 Digital input 5 (Terminal 12)
8.06 Digital input 6 (Terminal 13)
Relay output indicator (Terminals 15 &
8.07
16)
8.08~
Not used
8.10
8.11 Digital input / output 1 invert
8.12 Digital input 2 invert
8.13 Digital input 3 invert
8.14 Digital input 4 invert
8.15 Digital input 5 invert
8.16 Digital input 6 invert
8.17 Relay state invert
8.18~
Not used
8.20
8.21 Digital input 1 destination / output source
8.22 Digital input 2 destination
8.23 Digital input 3 destination
8.24 Digital input 4 destination
8.25 Digital input 5 destination
8.26 Digital input 6 destination
8.27 Relay source
8.28 Not used
8.29 Logic input polarity
8.30 Not used
8.31 Activate digital output 1
8.32~
Not used
8.38
Disable digital inputs 5 and 6 auto
8.39
selection
8.40 Digital input 6 as thermistor input
66
Range Type
0 or 1 RO Bit
0 or 1 RO Bit
0 or 1 RO Bit
0 or 1 RO Bit
0 or 1 RO Bit
0 or 1 RO Bit
0 or 1 RO Bit
0 or 1 RW Bit
0 or 1 RW Bit
0 or 1 RW Bit
0 or 1 RW Bit
0 or 1 RW Bit
0 or 1 RW Bit
0 or 1 RW Bit
0.00 ~ 21.51 RW Uni
0.00 ~ 21.51 RW Uni
0.00 ~ 21.51 RW Uni
0.00 ~ 21.51 RW Uni
0.00 ~ 21.51 RW Uni
0.00 ~ 21.51 RW Uni
0.00 ~ 21.51 RW Uni
0 ~ 1 RW Bit
0 ~ 1 RW Bit
0 ~ 1 RW Bit
0 ~ 1 RW Bit
Default Setting
P
P
P
P
P
P
P
0
0
0
0
0
0
0
R P P10.03
R P P06.29
R P P06.30
R P P06.32
Reference
R P select
dependant
Reference
R P select
dependant
R P P10.01
R P 1
R 1
0
R 0
Commander SE Advanced User Guide
Update
Rate
L1
L1
L1
L1
L1
L1
L1
L1
L1
L1
L1
L1
L1
L1
I
I
I
I
I
I
I
I
L1
B
L1
Issue Number: 4
