Control Techniques Commander SE Advanced User's Manual page 100

The fieldbus option menu exists all the time within the drive. All the following Menu 15 parameters are stored in the drive
EEPROM, except those indicated. A generic description is given here, see the appropriate fieldbus module manual for more
details.
15.01
Fieldbus
Not Fitted
Profibus DP
Interbus S
CAN
15.02
0 ~ 99.99
0-9 0-9
X X
e.g. V03.02.01 = 3.02 (The ZZ component will be displayed in 15.50)
15.03
0 = Disabled
15.04
The selected baud rate depends upon the fieldbus module fitted. See relevant fieldbus for baud rate settings.
15.05
0 ~ 99.99
The selected data format / mode depends on the fieldbus module fitted.
NOTE
See relevant fieldbus manual for data format / mode settings.
15.06
-9999 ~ 9999
* Network Cycles per Second
Value
-2 Fieldbus initialisation failure.
-1 Initialisation complete but no network running.
0 Network running but no network cycles per second detected.
x Network cycles per second detected.
100
Fieldbus ID
0 ~ 255 0
ID
0
1
2
5
Fieldbus software version Vxx.yy
0-9 0-9
• Y Y
Fieldbus node address
0 ~ 255 0
Fieldbus baud rate
0 ~ 9 0
Data format / mode
0
Fieldbus diagnostic
Description
RW Uni
RW Uni
RW Uni
RW Uni
RW Uni
* RW Bi
Commander SE Advanced User Guide
Issue Number: 4
