Control Techniques Commander SE Advanced User's Manual page 86

11.27~
11.28
11.29
1.00 ~ 9.99
Indicates the version of drive software fitted
11.30
If any number other than 0 is programmed in this parameter a user security will be applied. When a user security code has
been programmed, none of the parameters in the basic parameter set can be altered.
11.31
11.32
1.50 ~ 70.00
This parameter indicates the drives continuous current rating in amps.
11.33
240 ~ 480
This parameter indicates the voltage rating of the drive.
11.34
Indicates the sub-version of drive software fitted.
11.35
Indicates the version of DSP software fitted.
11.36~
11.40
11.41
Sets the timeout in seconds for the drive display to revert to status mode from parameter mode following no action on the
keypad.
86
Unused parameters
Drive software version
User security code
0 ~ 9999 0
Unused parameter
Drive rated continuous current
Drive voltage rating
Drive software sub version
0 ~ 99
Drive DSP software version
0 ~ 9.9
Unused parameters
Status mode timeout
0 ~ 250 240
RO Uni
RW Uni
A RO Uni
V RO Uni
RO Uni
RO Uni
s RW Uni
Commander SE Advanced User Guide
P
S P
P
P
P
P
P
Issue Number: 4
