Menu 1: Speed reference selection, limits and filters

Parameter
1.01 Level of reference selected
1.02 Pre-filter reference
1.03 Pre-ramp reference
1.04 Not used
1.05 Jog reference
1.06 Maximum speed clamp
1.07 Minimum speed clamp
1.08~
Not used
1.09
1.10 Allow negative digital references
1.11 Reference enabled indicator
1.12 Reverse selected indicator
1.13 Jog selected indicator
1.14 Reference selector
1.15 Preset selector
1.16 Not used
1.17 Keypad reference
1.18 Precision reference
1.19 Precision reference trim
1.20 Precision reference update disable
1.21 Preset speed reference 1
1.22 Preset speed reference 2
1.23 Preset speed reference 3
1.24 Preset speed reference 4
1.25 Preset speed reference 5
1.26 Preset speed reference 6
1.27 Preset speed reference 7
1.28 Preset speed reference 8
1.29 Skip frequency 1
1.30 Skip frequency band 1
1.31 Skip frequency 2
1.32 Skip frequency band 2
1.33 Skip frequency 3
1.34 Skip frequency band 3
1.35 Reference in skip frequency band indicator
1.36 Analog reference 1
1.37 Analog reference 2
1.38~
Not used
1.40
1.41 Analog reference 2 select
1.42 Preset reference select
1.43 Keypad reference select
1.44 Precision reference select
1.45 Preset select bit 0
1.46 Preset select bit 1
1.47 Preset select bit 2
1.48 Not used
1.49 Reference selected indicator
1.50 Preset selected indicator
1.51 Power up keypad reference
* The maximum value is 1.06 or 21.01.
18
Range Type
±1000.0 Hz*
RO Bi
±Max
RO Bi
±Max
RO Bi
0 ~ 400.0Hz RW Uni
0 ~1000.0Hz RW Uni
0 ~ [1.06] RW Uni
0 or 1 RW Bit
0 or 1 RO Bit
0 or 1 RO Bit
0 or 1 RO Bit
0-5 RW Uni
0-8 RW Uni
±Max
RO Bi
±1000.0Hz
RW Bi
0 ~ 99mHz RW Uni
0 or 1 RW Bit
±1000.0Hz
RW Bi
±1000.0Hz
RW Bi
±1000.0Hz
RW Bi
±1000.0Hz
RW Bi
±1000.0Hz
RW Bi
±1000.0Hz
RW Bi
±1000.0Hz
RW Bi
±1000.0Hz
RW Bi
0 ~1000.0Hz RW Uni
0 ~ 5.0Hz RW Uni
0 ~1000.0Hz RW Uni
0 ~ 5.0Hz RW Uni
0 ~1000.0Hz RW Uni
0 ~ 5.0Hz RW Uni
0 or 1 RO Bit
±1000Hz*
RO Bi
±1000Hz*
RO Bi
0 or 1 RO Bit
0 or 1 RO Bit
0 or 1 RO Bit
0 or 1 RO Bit
0 or 1 RO Bit
0 or 1 RO Bit
0 or 1 RO Bit
1 ~ 5 RO Uni
1 ~ 8 RO Uni
0 ~ 2 RW Uni
Default Setting
P
P
P
1.5
50(EUR)
60(USA)
0.0
0
P
P
P
0(EUR)
Txt
4(USA)
0
S P 0.0
0.0
0
0
0.0
0.0
0.0
0.0
0.0
0.0
0.0
0.0
0.0
0.5
0.0
0.5
0.0
0.5
P
P
P
Txt 0
Commander SE Advanced User Guide
Issue Number: 4
Update
Rate
L2
L2
L2
L2
B
B
B
L1
L1
L1
L2
L2
B
L2
L2
L2
L2
L2
L2
L2
L2
L2
L2
L2
B
B
B
B
B
B
L2
L2
L2
L2
L2
L2
L2
L2
L2
L2
L2
L2
I
