Control Techniques Commander SE Advanced User's Manual page 171

Terminal Set-up (Negative Logic)
Frequency reference
Brake relay coil
Control circuit diagram
Up
Limit
switch
Speed Profile
#02
#15
#51
Commander SE Advanced User Guide
Issue Number: 4
0V common
1
2 Local voltage speed reference input (A1)
3 +10V reference output
4 0V common
5 Remote current speed reference input (A2)
6 Analog output (motor speed)
7 +24V output
8 Digital output
Q6
9 Digital enable / reset
K1
Run forward
K2
Run reverse
Local (A1) / Remote (A2) speed reference
T4
Jog
+24V output
Status relay (Drive healthy)
Status relay (Drive healthy)
Down
K1 K2
Q3
Brake
relay
Limit
switch contact
K2
K1 Q3 T4*
0~3sec
Up Down Motor brake
#03
T4
Commander SE
line MCB
Brake resistor
temperature
switch
Commander SE
Q6
line contactor
Stop
#04
Motor brake
171
