Control Techniques Commander SE Advanced User's Manual page 101

15.07
The delay time that is required for the loss of communications to cause a trip.
0 = Disabled
15.08
1 = Little (LSB 1st)
0 = Big (MSB 1st)
This parameter selects the order of bytes transmitted/received for cyclic data words.
15.09~
15.10
15.11~
15.12
* Parameter
0-9 0-9
X X
e.g. 11.28 = 11.28
0 = Disabled
15.13~
15.20
15.21~
15.22
* Parameter
0-9 0-9
X X
e.g. 11.28 = 11.28
0 = Disabled
15.23~
15.29
15.30
Cleared once defaults are loaded.
15.31~
15.49
15.50
Indicates the software sub version of the fieldbus module software.
Commander SE Advanced User Guide
Issue Number: 4
Trip delay time
0 ~ 9999 0
Endianism
0 or 1 0
Unused parameters
Cyclic IN mappings
0 ~ 96.99 0
0-9 0-9
Y Y
•
Unused parameters
Cyclic OUT mappings
0 ~ 96.99 0
0-9 0-9
• Y Y
Unused parameters
Load option defaults
0 or 1 0
Unused parameters
Software version zz (Reserved)
0 ~ 99
ms RW Uni
RW Bit
* RW Uni
* RW Uni
RW Bit
RO Uni
101
