4.10

DC Bus information

4.10.1 SE DC Bus levels
0V trip level
Braking level
Rated upper level (AC mains +10% x 1.4142)
Rated lower level (AC mains -10% x 1.4142)
*
UV reset level
UV trip level
Standard ramp voltage 2.08
* These are the absolute minimum DC voltages that the drive can be supplied with. If the drive is not supplied with at least
this voltage, it will not reset out of a UU trip at power up.
4.10.2 SE DC Bus design
Drive
SE11200025
SE11200037
SE11200055
SE11200075
SE2D200075
SE2D200110
SE2D200150
SE2D200220
SE23200400
SE23400075
SE23400110
SE23400150
SE23400220
SE23400300
SE23400400
Commander SE Advanced User Guide
Issue Number: 4
Bus capacitance Bus inductance
uF mH
390 N/A
390 N/A
780 N/A
780 N/A
940 N/A
1410 N/A
1410 N/A
1880 N/A
1880 N/A
235 N/A
235 N/A
235 N/A
470 N/A
470 N/A
470 N/A
200V drives 400V drives
420V 830V
390V 780V
372V 747V
255V 484V
235V 460V
180V 400V
EUR> 750V
390V
USA> 775V
Bus capacitance
Drive
SE33200550
SE33200750
SE33400550
SE33400750
SE43401100
SE43401500
SE43401850
SE53402200
SE53403000
SE53403700
Bus inductance
uF mH
1880 0.6
1880 0.6
470 1.7
470 1.7
1020 0.9
1020 0.9
1020 0.9
4400 0.85
4400 0.91
4400 0.63
129
