3.10

Menu10: Status and trips

Parameter
10.01 Drive healthy indicator
10.02 Drive running indicator
10.03 At zero speed indicator
10.04 At or below min. speed indicator
10.05 Below at speed window indicator
10.06 At speed indicator
10.07 Above at speed window indicator
10.08 At 100% load indicator
10.09 Current limit active indicator
10.10 Motor regenerating indicator
10.11 Dynamic brake active indicator
10.12 Dynamic brake alarm indicator
10.13 Direction demanded indicator
10.14 Direction running indicator
10.15 AC supply loss indicator
10.16 Not used
10.17 Motor current overload indicator
10.18 Drive temperature alarm indicator
10.19 General drive alarm
10.20 Last trip
10.21 Second last trip
10.22 Third last trip
10.23 Fourth last trip
10.24 Fifth last trip
10.25 Sixth last trip
10.26 Seventh last trip
10.27 Eighth last trip
10.28 Ninth last trip
10.29 Tenth last trip
10.30 Max full power braking time
10.31 Max full power braking period
10.32 External trip
10.33 Drive reset
10.34 No of auto-reset attempts
10.35 Auto-reset time delay
Hold drive healthy until last auto-
10.36
reset attempt
10.37 Stop drive on non important trips
10.38 User trip
10.39 Braking energy overload accumulator
10.40 Status word
Commander SE Advanced User Guide
Issue Number: 4
Range Type
0 or 1 RO Bit
0 or 1 RO Bit
0 or 1 RO Bit
0 or 1 RO Bit
0 or 1 RO Bit
0 or 1 RO Bit
0 or 1 RO Bit
0 or 1 RO Bit
0 or 1 RO Bit
0 or 1 RO Bit
0 or 1 RO Bit
0 or 1 RO Bit
0 or 1 RO Bit
0 or 1 RO Bit
0 or 1 RO Bit
0 or 1 RO Bit
0 or 1 RO Bit
0 or 1 RO Bit
0 ~ 200 RO Txt
0 ~ 200 RO Txt
0 ~ 200 RO Txt
0 ~ 200 RO Txt
0 ~ 200 RO Txt
0 ~ 200 RO Txt
0 ~ 200 RO Txt
0 ~ 200 RO Txt
0 ~ 200 RO Txt
0 ~ 200 RO Txt
0.0 ~ 400.0
RW Uni
secs
0.0 ~ 25.0 mins RW Uni
0 or 1 RO Bit
0 or 1 RW Bit
0 ~ 5 RW Uni
0.0 ~ 25.0 secs RW Uni
0 or 1 RW Bit
0 or 1 RW Bit
0 ~ 200 RW Uni
0.0 ~ 100.0% RO Uni
0 ~ 32767 RO Uni
Default
P
P
P
P
P
P
P
P
P
P
P
P
P
P
P
P
P
S P
S P
S P
S P
S P
S P
S P
S P
S P
S P
0
0
0
0
1.0
0
0
P 0
P
P
Setting Update Rate
L1 (set),
B (clear)
B
BF
BF
BF
BF
BF
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
BF
L3
B
B
B
B
B
B
B
77
