Control Techniques Commander SE Advanced User's Manual page 75

9.10
0.00 ~ 21.51
*Units: Menu.Parameter
This destination parameter defines the parameter to be controlled by logic function 1. Only a bit parameter can be
programmed as the destination. If a non valid parameter is programmed the output is not routed anywhere.
9.11~
9.20
9.21
If this parameter is set then the motorised pot output will be set to 0 each time the drive powers up.
9.22
When this bit is set to 0 the motorised pot output is limited to positive values only (0 - 100.0%). Setting it to 1 allows negative
outputs also (-100.0% - +100.0%).
9.23
This parameter defines the time taken for the motorised pot function to ramp from 0 to 100.0%. Twice this time will be taken
to adjust the output from -100.0% to +100.0%.
9.24
0.00 ~ 2.50
This parameter can be used to restrict the output of the motorised pot to operate over a reduced range so that it can be used
as a trim for example. There is an automatic scaling such that when this parameter is set to 1.00, a 100% level on the
motorised pot will cause the programmed destination parameter to be at its maximum value.
9.25
0.00 ~ 21.51
This needs to be set up with the parameter that the motorised pot is to control. Only non bit parameters which are not
protected can be controlled by the motorised pot function, if a non valid parameter is programmed the output is not routed
anywhere. If the motorised pot is to control speed then it is suggested that one of the preset speed parameters is entered
here.
9.26
9.27
Two input terminals must be programmed to control these parameters to implement the motorised pot.
9.28
When this parameter is set to 1 the motorised pot output is reset to zero.
Commander SE Advanced User Guide
Issue Number: 4
Prog. logic function destination
0.0
Unused parameters
Motorised pot zero start select
0 or 1 0
Motorised pot bipolar select
0 or 1 0
Motorised pot rate
0 ~ 250 20
Motorised pot scale factor
1.00
Motorised pot destination
0.00
Motorised pot up
Motorised pot down
0 or 1
Motorised pot reset
0 or 1 0
*
RW Uni
RW Bit
RW Bit
s RW Uni
RW Uni
*
RW Uni
RO Bit
RW Bit
R P
R P
75
