Menu 4: Current control

Parameter
4.01 Motor current magnitude
4.02 Motor active current
4.03 Not used
4.04 Current demand
4.05~
Not used
4.06
4.07 Current limit
4.08 Torque reference
4.09~
Not used
4.10
4.11 Torque mode selector
4.12 Not used
4.13 Current loop proportional gain
4.14 Current loop integral gain
4.15 Motor thermal time constant
4.16 Motor protection mode select
4.17 Motor magnetising current
4.18 Over-riding current limit
4.19 Overload accumulator
4.20 Drive load indicator
4.21 Load indication selector
