Menu 21: Second motor map

Parameter
21.01 Motor 2 maximum speed clamp
21.02 Motor 2 minimum speed clamp
Motor 2 speed reference
21.03
selector
21.04 Motor 2 Acceleration ramp rate
21.05 Motor 2 Deceleration ramp rate
21.06 Motor 2 rated frequency
21.07 Motor 2 motor rated current
Motor 2 motor rated full load
21.08
rpm
21.09 Motor 2 motor rated voltage
21.10 Motor 2 rated power factor
21.11 Motor 2 number of poles
21.12 Motor 2 stator resistance
21.13 Motor 2 voltage offset
21.14 Motor 2 leakage inductance
21.15 Motor map 2 active
102
Range Type
0 ~ 1000.0 Hz RW Uni
0 ~ P21.01 Hz RW Uni
(0) A1.A2
(1) A1.Pr
(2) A2.Pr
RW Txt
(3) Pr
(4) Pad
(5) Prc
0.0 ~ 3200.0
RW Uni
s/100Hz
0.0 ~ 3200.0
RW Uni
s/100Hz
1000.0 Hz RW Uni
0 ~ Drive rating RW Uni
0 ~ 9999rpm RW Uni
400V unit =
0 ~ 480V
RW Uni
200V unit =
0 ~ 240V
0 ~ 1.00 RW Uni
Auto
RW Uni
2P ~ 8P(0-4)
0 ~ 99.99Ω RW Uni
0 ~ 25.5V RW Uni
000.0 ~ 500.0mH RO Uni
0 ~ 1 RO Bit
Default
EUR> 50.0
USA> 60.0
0.0
EUR> (0)A1.A2
USA> (4)Pad
5.0
10.0
EUR> 50.0
USA> 60.0
Drive rating
EUR> 1500
USA> 1800
EUR>
400V unit =400V
200V unit =230V
USA>
400V unit =460V
200V unit =230V
0.85
Txt Auto (0)
P 0.0
P
P
P 0
Commander SE Advanced User Guide
Setting Update Rate
B
B
L2
L2
L2
BS, MC
BS, MC
BS, MC
BF, MC
BS, MC
BS, MC
BS, MC
BF, MC
A
B
Issue Number: 4
