Control Techniques Commander SE Advanced User's Manual page 68

8.18~
8.20
8.21
8.22
8.23
8.24
8.25
8.26
8.27
Source: 0.00 ~ 21.51
*Units: Menu.Parameter
Destination parameters define the parameter each of the programmable inputs is to control. Only Bit parameters which are
not protected can be controlled by the programmable digital inputs. If a non-valid parameter is programmed, the digital input
is not routed anywhere.
Source parameters define the parameter to be represented at the digital output terminal or relay. Only Bit parameters can be
selected as a source for a digital output. If a non-valid parameter is programmed, then the digital output will remain in the
inactive state and the relay will remain in the de-energised state.
Terminal
8
9
10
11
12
13
15 & 16
8.29
This parameter changes the logic polarity on the digital inputs. In its default state the input polarity is positive logic which
requires the digital inputs to be driven high to activate the input. When this parameter is set to a 0, the input polarity is
negative logic which requires the digital inputs to be pulled low to activate the input.
NOTE
A change to the logic input polarity will only be implemented if the drive is disabled or tripped and the Stop/Reset
key is pressed or a Reset command is given over serial comms. The Run terminals should be open when any
change is implemented.
8.30
8.31
This parameter is set to 1 for Terminal 8 to be an output and set to a 0 for Terminal 8 to be an input.
68
Unused parameters
Digital input 1 destination / output source
Digital input 2 destination
Digital input 3 destination
Digital input 4 destination
Digital input 5 destination
Digital input 6 destination
Relay source
Destination/
source Function
parameter
Input destination/
8.21
Output source
8.22 Input destination
8.23 Input destination
8.24 Input destination
8.25 Input destination
8.26 Input destination
8.27 Relay source
Logic input polarity
0 or 1 1
Unused parameter
Activate digital output 1
0 or 1 1
*
RW Uni
Default
Default description
parameter
10.03 Zero speed (output)
6.29 Enable
6.30 Run Forward
6.32 Run Reverse
6.31 Jog
1.41 Local / Remote
10.01 Drive Healthy
RW Bit
RW Bit
Commander SE Advanced User Guide
R P
Comments
See parameter 6.04 for
further set-up information
Reference select dependant.
See parameter 1.14
R P
R
Issue Number: 4
