Menu 3: Speed sensing thresholds

Parameter
3.01~
Not used
3.04
3.05 Zero-speed threshold
3.06 At speed window threshold
3.01 ~
3.04
3.05
0.0 ~ 20.0
If the post-ramp frequency reference (2.01) is at or below the setting of this parameter in either direction, the 'zero speed'
indicator (10.03) is set to 1, otherwise the indicator is set to 0.
3.06
0.0 ~ 20.0
The 'At speed' window threshold defines the boundary around the set speed point in which the 'At speed' indication (10.06) is
set to 1.
The 'At speed' window is defined as Set speed ± (3.06/2).
Commander SE Advanced User Guide
Issue Number: 4
Range
0.0 ~ 20.0Hz
0.0 ~ 20.0Hz
Unused parameters
Zero-speed threshold
1.0
At speed window threshold
1.0
Type Default
RW Uni
RW Uni
Hz RW Uni
Hz RW Uni
Setting Update Rate
1.0
1.0
B
B
33
