Control Techniques Commander SE Advanced User's Manual page 63

7.10
7.14
0.00 ~ 21.51
*Units: Menu number.Parameter number
Default settings:
7.10 = 1.36
7.14 = 1.37
The parameter which the relevant analog input is required to control is programmed here. Only non-bit parameters which are
not protected can be controlled by analog inputs. If a non valid parameter is programmed to the destination of an analog
input, the input is not routed anywhere.
After modification of this parameter, the destination is only changed when a reset is performed.
7.11
Terminal 5 is the analog current reference input. The setting of this parameter configures the terminal for the required mode.
0 0-20
1 20-0
2 4-20
3 20-4
4 4-.20
5 20-.4
In modes 2 and 3, a current loop loss trip (cL) will be generated if the current input falls below 3mA.
NOTE
If 4-20mA or 20-4mA modes are selected and the drive trips on current loop loss (cL), analog reference 1 cannot be
selected if the current reference is less than 3mA.
If 4-.20mA or 20-.4mA modes are selected, parameter 7.28 will switch from 0 to 1 to indicate that the current
reference is less than 3mA.
7.15 ~
7.18
7.19 Analog output source selector (Terminal 6)
0.00 ~ 21.51
*Units: Menu.Parameter
(See parameter 7.33 for further set up information)
For default settings:
0V = 0Hz
+10V = value set in parameter 1.06
The parameter required to be represented as an analog signal on terminal 6 is programmed here. Only non-bit parameters
which are not protected can be programmed as a source. If a non valid parameter is programmed as a source, the output will
remain at 0 (zero).
NOTE
Customers wishing to output load should be aware of the maximum values of the parameters they are routing to the
output.
The maximum value of 4.02 (active current) is the maximum current that the drive can deliver 1.5 x drive rating. Therefore, at
rated load the analog output will be 1/1.5 x 10 = 6.66V.
The maximum value of 4.02 (active current) is the maximum level of current that the drive can operate at which is drive rating
x 1.5. The maximum value of 4.20 is the active current limit (4.18) and therefore the analog output will be at 10V when the
load is at its maximum. Users wishing to see 10V output at 100% load will need to set a scale factor in 7.20 equal to 4.18 /
100 to achieve this.
Commander SE Advanced User Guide
Issue Number: 4
Analog input 1 destination parameter
Analog input 2 destination parameter
See below
Analog input 1 routed to analog reference 1
Analog input 2 routed to analog reference 2
Analog input 2 mode selector
0 ~ 5 4
0 to 20mA
20 to 0mA
4 to 20mA with trip on loss of signal
20 to 4mA with trip on loss of signal
4 to 20mA with no trip on loss of signal
20 to 4mA with no loss on trip of signal
Unused parameters
2.01 (Post
ramp
reference)
*
RW Uni
RW Uni Txt
*
RW Uni
R P
P
63
