Menu 11: Miscellaneous - Control Techniques Commander SE Advanced User's Manual

3.11

Menu 11: Miscellaneous

Parameter
11.01~
Not used
11.20
11.21 Parameter scaling
Parameter displayed at power up
11.22
select
11.23 Serial comms address
11.24 Serial comms mode
11.25 Serial comms baud rate
Serial comms minimum transmit
11.26
delay
11.27~
Not used
11.28
11.29 Drive software version
11.30 User security code
11.31 Not used
11.32 Drive rated continuous current
11.33 Drive voltage rating
11.34 Drive software sub version
11.35 Drive DSP software version
11.36~
Not used
11.40
11.41 Status mode timeout
11.42 Parameter cloning
11.43 Load default parameters
11.44 Security status
11.45 Select motor 2 parameters
84
Range Type
0.00 ~ 99.99 RW Uni
0 or 1 RW Bit
0.0 ~ 24.7
RW Uni
Group.Unit
(0) Ansi
(1) rtu RW Txt
(2) F.bus
(0) 2.4
(1) 4.8
RW Txt
(2) 9.6
(3) 19.2
0-250mS RW Uni
1.00 ~ 9.99 RO Uni
0 ~ 9999 RW Uni
1.50 ~ 70.0A RO Uni
240 ~ 480V RO Uni
0 ~ 99 RO Uni
0 ~ 9.9 RO Uni
0 ~ 250secs RW Uni
(0) no
(1) rEAD
(2) Prog RW Uni
(3) Auto
(4) boot
(0) no
(1) Eur
(2) USA RW Uni
(3) br.Eu
(4) br.US
(0) L1
(1) L2 RW Uni
(2) Loc
0 or 1 RW Bit
Default Setting
1.00
0
1.1
R 0
(1)4.8
20
P
S P 0
P
P
P
P
P 240
Txt R (0)no
Txt R (0)no
Txt R (0)L1
0
Commander SE Advanced User Guide
Update Rate
B
B
BF
BF, L1
BF
BF, L1
I
B
I
I
I
B
B
B
B
B
B
Issue Number: 4
