Battery Operation

Operational Readiness
Operating Position
Revision B
Technical Specifications: Recording
„
Type: nickel-cadmium
„
Rated battery voltage 18 V
„
Rated battery capacity 1.3 Ah
„
Fully charged battery sufficient for up to 50 Automatic mode 1-page
ECGs, provided recorder is only switched on to record the ECGs.
„
Charge time for depleted battery approximately 4 hours (minimum
charge time for 1 Automatic mode ECG: 10 minutes)
„
Battery life approximately 2 to 3 years, replacement by service only
„
Lithium battery for built-in clock, battery life approximately 5 years,
replacement by service only
Battery Maintenance
The battery in the MAC 1200 unit should be exercised regularly. This
means the battery should be allowed to drain between charging cycles.
If the ECG unit is left connected to wall power and/or only used
sporadically on battery power, a discharge cycle should be performed on
a monthly basis.
Turn the MAC 1200 unit on, and allow the battery to drain. When the
Battery Low indicator illuminates, the unit can be connected to wall
power and allowed to recharge.
Use a battery maintenance chart to track the discharge cycles
After successful self-test, approximately 10 seconds after power-up.
Horizontal
MAC 1200
2012250-022
13-11
