Communication

Baud Rate (PC)

Protocol

Modem

Revision B
System Setup: Communication
Transmission rate for the selected protocol. We recommend the default
setting of [19200 baud].
The recorder offers two communication protocols: "A5" and "CSI".
With the "A5" protocol, the 10-second resting ECG can be transmitted to
CardioSys and CardioSoft.
The CSI protocol supports the transfer of resting ECGs from the
electrocardiograph to a MUSE CV system.
Select the modem type. Choose among the standard modems MultiTech
(MT 19.2, 56k), Elsa 14.4, 28.8, 33.6, 56k and a user-defined modem.
When using one of the standard modems, enter the following:
„
The dial mode (pulse or tone, depending on your telephone network).
„
The telephone number (20 digits maximum).
„
The number to access the public telephone network (e.g. "0").
For a user-defined modem, enter the following:
„
The telephone number (20 digits maximum).
„
The init string (20 characters maximum). (See modem operator's
manual.)
„
The dial string (20 characters maximum). (See modem operator's
manual.)
„
The hangup mode (20 characters maximum). (See modem operator's
manual.)
MAC 1200
2012250-022
9-25
