Arrhythmia Mode

Report Sequence

Gain

Muscle Filter

AC Filter

9-12
System Setup: Arrhythmia Mode
Use the cursor keys to position the bar cursor on Arrhythmia and confirm
the selection with .
The configuration menu for the Arrhythmia mode will appear.
[STD_C]: V1, V2, V3, V4, V5, V6
STD_RED: I, II, III, V2, V4, V6
STD_LI: I, II, III, aVR, aVL, aVF
CABR_LI: aVL, I, -aVR, II, aVF, III
HIGH_C: V1', V2', V3', V4', V5', V6'
(C = chest leads, RED = reduced number of leads, LI = limb leads)
„
Position the cursor on HIGH_C.
„
Press and create the report sequence as described in
setup
Mode" section.
The unit will automatically determine the gain setting (*auto, 5, [10], 20,
40 mm/mV; with "*auto").
Elimination of muscle artifact: yes, [no].
Elimination of AC line interference: [yes], no.
MAC 1200
2012250-022
"6 Lead
Revision B
