Recording

Revision B
Arrhythmia Mode Recording: Recording
1. After switching on the unit, press
mode.
When working with the MAC 1200 ST equipped with the Stress Test
option ERGO, you must press the button twice.
2. Before recording the ECG, patient data can be entered (
recommended that you enter the patient's name to annotate it on
every report.
Before initiating a recording, check the display for error messages.
Check all electrodes; if the message persists, there must be a break
in the patient cable. Replace the cable with a new one.
3. Start and stop the recording with the
Table 2. Messages Indicating Disconnected Electrodes
Symbol
*RL*: right leg electrode disconnected
*RA*: right arm electrode disconnected
*LA*: left arm electrode disconnected
*LL*: left leg electrode disconnected
*V1*: chest electrode V1 disconnected
*V2*: chest electrode V2 disconnected
*V3*: chest electrode V3 disconnected
*V4*: chest electrode V4 disconnected
*V5*: chest electrode V5 disconnected
*V6*: chest electrode V6 disconnected
*RL*: right leg electrode disconnected
*RA*: right arm electrode disconnected
MAC 1200
2012250-022
to select the Arrhythmia
arrhy
pat
info
key.
Definition
). It is
7-5
