6 Lead Mode

Report Sequence

Revision B
System Setup: 6 Lead Mode
Use the cursor keys to position the bar cursor on 6 Lead and confirm the
selection with .
The configuration menu for the 6 Lead mode appears.
[STANDARD] (l, II, III, aVR, aVL, aVF, VI, V2, V3, V4, V5, V6)
CABRERA (aVL, l, -aVR, II, aVF, III, VI, V2, V3, V4, V5, V6)
SEQ. NO. 4 (users can define a custom report sequence here):
„
Position the cursor on SEQ. NO. 4.
„
Press .
setup
The display shown below will appear.
Report sequence
Chan. 1:
Chan. 2:
Chan. 3:
Chan. 4:
Chan. 5:
Chan. 6:
Chan. 7:
Chan. 8:
Chan. 9:
Chan. 10:
Chan. 11:
Chan. 12:
Press .
MAC 1200
2012250-022
SEQ. NO. 4
Lead Label
I I
II II
III III
AVR AVR
AVL AVL
AVF AVF
V1 V1
V2 V2
V3 V3
V4 V4
V5 V5
V6 V6
9-9
