Direct ECG Transmission

Selecting the Communication Protocol

Revision B
System Setup: Direct ECG Transmission
„
Select the 12 Lead mode and press
„
Press to display the configuration menu for the 12 Lead mode.
„
Use the cursor keys to position the bar cursor on Manual copy to
HOST and confirm the selection with
„
Press to clear the configuration menu.
„
Use the cursor keys to position the bar cursor on Communication and
confirm the selection with
„
Select the same baud rate as at the receiving modem (2400, 4800,
9600, 19200, 38400, 57600).
This adjustment is only necessary with MAC 1200 units, because this
device can send data to CardioSys/CardioSoft or to the MUSE system.
1. Using the cursor keys, position the bar cursor on Protocol.
2. Select the protocol A5 if you will send data to CardioSys/CardioSoft
system or select CSI to send data to MUSE system.
3. Use the cursor keys to position the bar cursor on Modem, none and
confirm the selection with
MAC 1200
2012250-022
.
copy
([HOST]).
.
.
9-31
