BASIC OPERATION

Turning ON the transceiver

NOTE: Before using the transceiver for the first time,
the battery pack must be fully charged for optimum
life and operation. See the INSTRUCTIONS for
details.
Portable:
Rotate [VOL] to turn ON the transceiver.
• The battery voltage or the opening text may be displayed,
depending on the presetting.
Mobile:
Push the Power key to turn ON the transceiver.
• The opening text may be displayed, depending on the
presetting.

D Adjusting the audio level

When receiving a call, rotate [VOL] to adjust the audio
output level to a comfortable listening level.

D Entering the password

Portable: For the Ten-key and the Simple key types
Mobile: For the LCD type
1. If the transceiver is preset for a Power ON
password when turning ON the transceiver, the
"User Password" screen is displayed, as shown to
the right.
2. Push [Up], [Down], [Right], or [Left] to select a
number, then push [OK] to enter.
3. Repeat step 2 to enter the password.
4. After entering the correct password, the
transceiver automatically displays the standby
screen.
NOTE: If the transceiver does not display the
standby screen after entering the password, the
entered code may be incorrect. In this case, push
[Back] several times until you delete the incorrect
code, and then enter the correct code.
TIP: For the Portable Ten-key type transceiver or
optional HM-218, HM-220T, HM-221T, a user can
enter the password with the keypad.
[OK]
[VOL]
Standby screen
3-2
[VOL]
[Up], [Down],
[Right], [Left]
[OK]
Power key
[Up], [Down],
[Right], [Left]
