6
MENU SCREEN

Trunking

Roaming Request
(For the Multi-site Trunk operation)
In the Digital mode
Turns the Roaming Request function ON or OFF.
When this function is turned ON, the transceiver starts
a Roaming Scan, regardless of the error rate. (p. 7-17)
L If the Site Lock function is turned ON, the transceiver
resumes a Roaming Scan when this function is turned
ON.
Site Select
(For the Multi-site Trunk operation)
In the Digital mode
Displays the "Site Select" screen. Then, push [Up] or
[Down] to select a site. After selecting, push [OK] to
save. (p. 7-19)
Site Lock
(For the Multi-site Trunk operation)
In the Digital mode
Turns the Site Lock function ON or OFF. When
this function is turned ON, the transceiver cancels
resuming a Roaming Scan, and stays on the current
site, regardless of the error rate. (p. 7-18)

Functions

Ext CH Sel Mode
Turns the External Channel Select function ON or
OFF.
When this function is ON, Memory channels are
selectable by only external input.
NOTE: This function is activated when the external
unit is connected to the transceiver. To use the
function, set "MCH Select:1" ~ "MCH Select:
5" to any pins, in the Port Setting screen of the
programming software.
Hook Scan (For the Mobile types)
Turns the On Hook Scan function ON or OFF.
When this function is ON, after putting the microphone
in its hanger (on-Hook), the transceiver automatically
starts scanning.
Horn (For the Mobile types)
Turns the Horn function ON or OFF.
When this function is ON, the HORN terminal of the
D-Sub 25 pin or Option Connector 22 pin is activated
after receiving a call with the Dec EXO or RX EXO
setting is ON.
L This function is useful when the user is away from the
transceiver.
L An external horn is required.
Keyset
In the Digital mode
Selects Keyset 1 or Keyset 2 for the Encryption
function.
NOTE:
• To use the function, the optional UT-134
encryption unit
• The Keysets are settable in the optional CS-KLD2
key loader software
Lone Worker
Turns the Lone Worker function ON or OFF.
When this function is ON, the transceiver
automatically enters the Emergency mode if no
operation occurs during the preset period.
Public Address (For the Mobile types)
Adjusts the Audio Output level of the connected Public
Address (PA).
6-10
aes
is required.
.
/
des
