4
ADVANCED OPERATION

DTMF calls

D Manual Dialing

A user can send DTMF codes.
While holding down [PTT], push the keys on the Ten-
key pad.

D Hot DTMF

A user can send DTMF codes using the Hot DTMF
function.
Without holding down [PTT], push the keys on the
Ten-key pad to send DTMF codes.
NOTE: Set the related settings using the CS-F3400D
programming software
function. See the Help file for details.

D Autodial

A user can quickly send DTMF tones that have been
pre-entered into the transceiver.
1. Push [DTMF Autodial] to display the "DTMF
Autodial" screen.
2. Push [Up] or [Down] to select a DTMF Memory.
3. Push [PTT] to send the selected DTMF Memory's
codes.
• After sending, automatically returns to the standby
screen.
TIP: In the standby screen, a user can send the
currently selected DTMF Memory's codes by
holding down [Autodial].
when using the Hot DTMF

D Stun function

(Only for LTR operation)
The Stun function is used when a transceiver is stolen
or lost, and the function deactivates the transceiver.
When the transceiver receives a matching DTMF
code, the stun function is activated and the transceiver
operation is inhibited. In this case, entering the
password or reprogramming is necessary to operate
the transceiver again.
4-2
