Table 36: RJ-45 Management Port Connector Pinout Information
Pin
2
3
4
5
6
7
8

Console Port Connector Pinouts for the QFX Series

The console port (labeled CON, or CONSOLE) is an RS-232 serial interface that uses an RJ-45 connector
to connect to a console management device. The default baud rate for the console port is 9600 baud.
Table 37 on page 86
provides the pinout information for the RJ-45 console connector. An RJ-45 cable
and RJ-45 to DB-9 adapter are supplied with the QFX Series device.
NOTE: If your laptop or PC does not have a DB-9 plug connector pin and you want to connect
your laptop or PC directly to a QFX Series device, use a combination of the RJ-45 cable and
RJ-45 to DB-9 adapter supplied with the device and a USB to DB-9 plug adapter. You must
provide the USB to DB-9 plug adapter.
Signal
TRP1—
TRP2+
TRP3+
TRP3—
TRP2—
TRP4+
TRP4—
(Continued)
Description
Transmit/receive data pair 1
Transmit/receive data pair 2
Transmit/receive data pair 3
Transmit/receive data pair 3
Transmit/receive data pair 2
Transmit/receive data pair 4
Transmit/receive data pair 4
85
