Specifications - Hypertherm ArcGlide Torch Height Control Instruction Manual

Voltage sensing, torch height control (thc) system that is designed for plasma cutting applications on an x-y cutting table
Hide thumbs
Table of Contents

Advertisement

SPeCIfICAtIoNS

Cutting table
Workpiece
Gantry
ArcGlide lifter
ArcGlide control
module
ArcGlide HMI
Star ground
(optional)
Plasma system
CNC
Rails
example of an ArcGlide tHC installed on a cutting table with a plasma system and CNC
Note: The ArcGlide control module and Ethernet switch should be located in an electrical cabinet that is
electrically grounded and environmentally clean.
