ArcGlide plasma interface discrete connection to any plasma system

No connection
J2 Inputs
Not connected
Not connected
Common
Common
Common
Common
Common
Spare in
Common
Not ready
Common
Ramp error
Common
Electrode (-)
Error
Common
Motion
Work (+)
Shield
Arc voltage sense wires. Use
~0.9 mm squared (18 AWG)
twisted pair wire, rated 600 V or
greater
2-24
2
J3 outputs
Field 24 V out
Field 24 V out
Common D1
Common PLASMA ON
Remote On B
Remote On A
D2
Spare out B
PLASMA STRT
Spare out A
Plasma Start B
Plasma Start A
D3
Hold B
ARC XFER
Hold A
Pierce B
D4
Pierce A
THC ON
Corner B
Corner A
Plasma interface (090052)
to plasma system
machine interface
to plasma system
eLeCtRoDe -
to plasma system
WoRK +
J2-16
J2
NO CONNECT
J2-15
FUTURE USE NO CONNECT
J2-14
COMMON
J2-13
COMMON
J2-12
COMMON
J2-11
COMMON
J2-10
COMMON
FIELD COMMON
* 24V
PULL UP
J2-9
SPARE IN
J2-8
FIELD COMMON COMMON
* 24V
PULL UP
J2-7
NOT READY
J2-6
FIELD COMMON COMMON
* 24V
PULL UP
J2-5
RAMP ERROR
J2-4
FIELD COMMON
COMMON
* 24V
PULL UP
J2-3
ERROR
J2-2
FIELD COMMON COMMON
* 24V
PULL UP
*Note: 24 V pullups on inputs are active only if they are set to "dry" on the
J2-1
MOTION **
**Note: the minimum connections required are Plasma Start and Motion.
J3
24V
J2-16
+24V THC
FOR I/O USE IF NEEDED
J2-15
500MA MAX
J2-14
J2-13
FIELD COMMON
J3-12
REMOTE ON
RELAY J3-11
J3-10
SPARE
RELAY J3-9
J3-8
PLASMA START
RELAY
J3-7
J3-6
HOLD
RELAY J3-5
J3-4
PIERCE
RELAY J3-3
J3-2
CORNER
RELAY J3-1
ArcGlide control module.
Use other signals if they are supported by the plasma system
ArcGlide THC Instruction Manual
FIELD +24V OUT
FIELD +24V OUT
COMMON
COMMON
REMOTE ON B
REMOTE ON A
SPARE OUT B
SPARE OUT A
PLASMA START **
PLASMA START A **
HOLD B
HOLD A
PIERCE B
PIERCE A
CORNER B
CORNER A
