Thc Controller Interface (228577) - Hypertherm ArcGlide Torch Height Control Instruction Manual

MAINteNANCe

tHC controller interface (228577)

4-46
J1 board interconnects
PCb back view
100
99
50
49
J6 J5
CNC I/o Plasma I/o
(male) (female)
1 4 4
34 37 37
PCb front view
tHC controller interface PCb
J3 to transformer
Pin number
1
2
3
4
5
6
7
8
J3 to transformer
Motor drive
52
51
2
1
J7 J4
op-Con I/o Lifter I/o
(female) (male)
1
1
3 1
14 12
21
34
Signal
115 V input 1
115 V input 2
115 V input 3
115 V input 4
45 V output line 1
45 V output line 2
22 V output line 1
22 V output line2
1
4
24
ArcGlide THC Instruction Manual
