Pin number Signal
1 Motor +
2 Motor –
3 Brake –
4 Common –
5 Power +24 VDC
6 Ohmic contact sense common
7 Ohmic contact sense
8 Ohmic contact sense bias +12 VDC
9 Encoder common
10 Lifter station active
11 Encoder input B –
12 Encoder input B +
Pin number Signal
1 RS422 RX +
2 RS422 RX –
3 RS422 Tx +
4 RS422 Tx –
5 RS422 common
6 Motion input +
7 Motion input –
8 Error input +
9 Error input –
10 Rampdown error input +
11 Rampdown error input –
12 Not ready input +
13 Not ready input –
14 Spare input +
15 Spare input –
16 Corner output A
17 Corner output B
18 Pierce output A
19 Pierce output B
ArcGlide THC Instruction Manual
J4 Lifter interface
Pin number Signal
13
14
15
16
17
18
19
20
21
22
23
24
J5 Plasma interface
Pin number Signal
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
MAINteNANCe
Encoder input A –
Encoder input A +
Common –
Change consumables switch +
Lifter down switch +
Lifter up switch +
Breakaway switch +
Upper limit switch +
Lower limit switch +
Not connected
Common –
Not connected
Hold output A
Hold output B
Start output A
Start output B
Spare output A
Spare output B
Remote on output A
Remote on output B
Common
Common
Common
+24 VDC output
+24 VDC output
+24 VDC output
1/50 Arc voltage +
1/50 Arc voltage –
Not connected
Not connected
4-49
