MAINteNANCe
Pin number Signal
1 Cycle Start input +
2 Cycle Start input –
3 Low gain input +
4 Low gain input –
5 AVC Disable input +
6 AVC Disable input –
7 IHS Sync input +
8 IHS Sync input –
9 Spare Input 1 +
10 Spare Input 1 –
11 Spare Input 2 +
12 Spare Input 2 –
13 IHS Complete output A
14 IHS Complete output B
15 Retract complete output A
16 Retract complete output B
17 Machine Motion output A
18 Machine Motion output B
19 THC Error output A
4-50
2
J7 op-Con interface
Pin number Signal
1 Not connected
2 Manual disable switch input +
3 Manual select switch input +
4 Torch up switch input +
5 Torch down switch input +
6 Spare switch input +
7 Common
8 Torch enabled output A
9 Torch enabled output B
10 Error output A
11 Error output B
12 Spare output A
13 Spare output B
14 Power +24 VDC output
J6 CNC interface
Pin number
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36 and 37
Signal
THC Error output B
Torch Breakaway output A
Torch Breakaway output B
CNC Spare output A
CNC Spare output B
Interlock input +
Interlock input –
Interlock output A
Interlock output B
Common
Common
Common
Common
+24 VDC output
+24 VDC output
+24 VDC output
Not connected
