Hypertherm ArcGlide Torch Height Control Instruction Manual page 184

MAINteNANCe
Pin numbers Signal
51 Lifter Manual Down input
53 Lifter Change Consumable
55 Encoder A
57 Encoder B
59 +5 VDC
61 Op-Con Disable input
63 Op-Con Select input
65 Op-Con Torch Up input
67 Op-Con Torch Down input
69 +5 VDC
71 Op-Con Spare input
73 Not connected
75 Not connected
77 Not connected
79 +5 VDC
81 Torque DAC
83 Drive Enable output
85 Not connected
87 Not connected
89 +5 VDC
91 Drive Fail input
93 Not connected
95 Ground
97 Ground
99 +5 VDC
4-54
J3 board interconnects (continued)
Pin numbers Signal
52 Op-Con Enabled output
54 Op-Con Error output
56 Op-Con Spare output
58 Not connected
60 Ground
62 1/50 Arc V –
64 1/50 Arc V+
66 Ohmic contact sense –
68 Ohmic contact sense common
70 Ground
72 Power good low active
74 Line Volts
76 Actual current
78 Not connected
80 Ground
82 +24 V Field
84 +12 V Field
86 +5 V Field
88 –12 V Field
90 Ground
92 Not connected
94 Reserved low active
96 Ground
98 Ground
100 Ground
