Arcglide Plasma Interface With Discrete Connection To Max200, Ht2000, Or Ht2000 Lhf Plasma System - Hypertherm ArcGlide Torch Height Control Instruction Manual

J2
Shield
electrode (-)
blue
Red
Work (+)
ArcGlide THC Instruction Manual
No connection
16 16
J3
Common
Motion
Plasma Start B
Plasma Start A
Hold B
Hold A
1 black
1
blue
black
White
1x6 Machine interface cable
Plasma interface termination
Signal Wire color
Plasma Start A Blue
Plasma Start B Black
Hold A White
Hold B Black
Motion Red
Common Blue
Ring terminal to ground stud Shield wire No connection
to plasma system
Use ~0.9 mm squared (18 AWG) twisted pair wire, rated 600 V or greater
ArcGlide plasma interface with discrete connection to MAX200, Ht2000, or Ht2000 LHf plasma system
PLASMA START
for Ht2000 and Ht2000LHf, set
ArcGlide plasma inputs to dry contact
by sliding the switch on the control
module to D.
Numbers in () refer to Ht2000 and
Ht2000 LHf.
HOLD IGNITION
Remove
Replace with
bushing 008245
Pin Cable label
Refer to Ht2000, Ht2000LHf manual
for the 1x6 connection.
9 82
15 83
1 87
5 86
36 (37) 84
31 (32) 85
J3-7 START - BLU
RELAY J3-8 START - BLK
J3-5 HOLD - WHT
IHS SYNC
RELAY J3-6 HOLD - BLK
24V
PULL UP
MOTION - RED
J2-1
J2-2 MOTION - BLU
FIELD COMMON
ArcGlide plasma interface
terminal blocks
to plasma system
eLeCtRoDe -
to plasma system
WoRK +
the plasma interface is mounted
externally by the customer.
9
+24V
START
15
COMMON
1
+24V
HOLD
5
COMMON
36(37)
MACHINE MOTION
31(32) DELAYED
( ) - FOR HT2000, HT2000LHF
Machine interface 1x6 CPC connector
MAX200
2-21
