HMI Parameter Value
ERR 7 FAILED MOVE TO IHS START
ERR 8 FAILED TO CONTACT PLATE
ERR 9 FAILED TO CLEAR PLATE
ERR 10 FAILED TO MOVE TO XFER HT
ERR 11 IHS SYNC TIMEOUT
ERR 12 TRANSFER TIMEOUT
ERR 13 LOST TRANSFER
ERR 14 FAILED MOVE TO PIERCE
ERR 15 FAILED MOVE CUTHEIGHT
ERR 16 RAMPDOWN TIMEOUT
ERR 17 RETRACT TIMEOUT
ERR 18 ERR SAMPLED ARC VOLTAGE
ERR 19 EXCESS PLATE CONTACT
ERR 20 PLASMA SUPPLY
ERR 21 OHMIC TIP SENSE
ArcGlide THC Instruction Manual
Normal errors (continued)
The lifter failed to reach IHS crossover height.
The torch failed to contact the workpiece
within 60 seconds.
The torch failed to retract and break Ohmic
contact within 10 seconds.
The torch failed to retract to Transfer Height
within 10 seconds.
The torch reached the IHS position but IHS
SYNC was not released within 60 seconds.
The Transfer signal was not received from the
plasma system within 60 seconds.
The plasma arc was lost during the cut.
The lifter failed to reach Pierce Start Height
within 10 seconds.
The lifter failed to reach Cut Height during
Accel Delay.
The Motion signal was not removed within
10 seconds.
The lifter failed to retract within 20 seconds at
the end of the cut.
During sample arc voltage operation, there was
an excessive change in sample voltage.
The torch made excessive contact with the
workpiece.
Plasma system error.
Ohmic Tip Sense was enabled but not sensed.
oPeRAtIoN
3-15
