Hypertherm ArcGlide Torch Height Control Instruction Manual page 177

Pin numbers Signal
1 CNC Cycle Start input
3 CNC IHS Disable input
5 CNC AVC Disable input
7 CNC IHS Sync input
9 +5 VDC
11 CNC Spare 1 input
13 CNC Spare 2 input
15 Interlock
17 Not connected
19 +5 VDC
21 Plasma Motion input
23 Plasma Error input
25 Plasma Ramp Error input
27 Plasma Not Ready input
29 +5 VDC
31 Plasma Spare input
33 Plasma RS422 RX
35 Not connected
37 Lifter Station Enable
39 +5 VDC
41 Lifter Lower Limit input
43 Lifter Upper Limit input
45 Lifter Breakaway input
47 Lifter Manual Up input
49 +5 VDC
ArcGlide THC Instruction Manual
J1 board interconnects
Pin numbers Signal
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
42
44
46
48
50
MAINteNANCe
CNC IHS Complete output
CNC Retract Complete output
CNC Machine Motion output
CNC Error output
Ground
CNC Breakaway output
CNC Spare output
CNC Dry Inputs 24 V
Not connected
Ground
Plasma Corner output
Plasma Pierce output
Plasma Hold output
Plasma Start output
Ground
Plasma Spare output
Plasma RS422 TX
Plasma Dry Inputs 24 V
Plasma Remote On output
Ground
Lifter Brake output
Not connected
Not connected
Not connected
Ground
4-47
