ArcGlide setup parameters (continued)
IHS Speed
Description: This parameter sets the slow speed for the final approach to the workpiece during an IHS operation. It
is also used as the slow speed for manual moves.
When to use: During installation.
How to use: With the Hypertherm 24.13-cm (9.5-inch) lifter, this value is set to 60 IPM. To avoid poor speed
regulation, do not set this value below 10% of Maximum Speed.
Example: 60 IPM
Pointer offset Side*
Description: This value is the offset distance between the torch center and the laser pointer when looking from the
side of the cutting machine.
When to use: During installation.
How to use: Use the precise distance between the laser spot and the center of the torch to fine tune this value.
Example: 6.6 cm (2.600 inches)
Pointer offset front*
Description: This value is the offset distance between the torch center and the laser pointer when looking from the
front of the cutting machine.
When to use: During installation
How to use: Use the precise distance between the laser spot and the center of the torch to fine tune this value.
Example: 11 cm (4.249 inches)
* Asterisks indicate values that may need to be adjusted.
