To view the interfaces and ports on which you enabled UDP helper, use the show ip udp-helper
command from EXEC Privilege mode.
Dell#show ip udp-helper
--------------------------------------------------
Port UDP port list
--------------------------------------------------
te 1/1 1000

Configuring a Broadcast Address

To configure a broadcast address, use the following command.
• Configure a broadcast address on an interface.
ip udp-broadcast-address
Examples of Configuring and Viewing a Broadcast Address
Dell(conf-if-vl-100)#ip udp-broadcast-address 1.1.255.255
Dell(conf-if-vl-100)#show config
!
interface Vlan 100
ip address 1.1.0.1/24
ip udp-broadcast-address 1.1.255.255
untagged GigabitEthernet 1/2
no shutdown
To view the configured broadcast address for an interface, use show interfaces command.
R1_E600(conf)#do show interfaces vlan 100
Vlan 100 is up, line protocol is down
Address is 00:01:e8:0d:b9:7a, Current address is 00:01:e8:0d:b9:7a
Interface index is 1107787876
Internet address is 1.1.0.1/24
IP UDP-Broadcast address is 1.1.255.255
MTU 1554 bytes, IP MTU 1500 bytes
LineSpeed auto
ARP type: ARPA, ARP Timeout 04:00:00
Last clearing of "show interface" counters 00:07:44
Queueing strategy: fifo
Input Statistics:
0 packets, 0 bytes
Time since last interface status change: 00:07:44

Configurations Using UDP Helper

When you enable UDP helper and the destination IP address of an incoming packet is a broadcast
address, Dell Networking OS suppresses the destination address of the packet.
The following sections describe various configurations that employ UDP helper to direct broadcasts.
• UDP Helper with Broadcast-All Addresses
• UDP Helper with Subnet Broadcast Addresses
• UDP Helper with Configured Broadcast Addresses
• UDP Helper with No Configured Broadcast Addresses
