5.5.11 CPU Control Group
The instructions in this group (Table 5-16) act upon the
CPU control and status registers or perform other functions
that do not fit into any of the other instruction groups. These
include two instructions used for returning from an inter-
rupt service routine. Return from Nonmaskable Interrupt
(RETN) and Return from Interrupt (RETI) are used to pop
the Program Counter from the stack and manipulate the
Interrupt Enable Flag (IEF1 and IEF2), or to signal a reset
to the Z80 peripherals family.
The Disable and Enable Interrupt instructions are used to
set/reset interrupt mask. Without a mask parameters, it
disables/enables maskable interrupt globally. With mask
data, it enables/disables interrupts selectively.
HALT and SLEEP instructions stop the CPU and waits for
an event to happen, or puts the system into the power save
mode.
Bank Test instructions reports which register file, primary
or alternate bank, is in use at the time, and reflect the status
Instruction Name
Bank Test
Disable Interrupt
Enable Interrupt
HALT
Interrupt Mode Select
Load Accumulator from I or R Register
Load I or R Register from Accumulator
Load I Register from HL Register
Load HL Register from I Register
Load Control
Mode Test
No Operation
Return from Interrupt
Return from Nonmaskable Interrupt
Reset Control Bit
Set Control Bit
Sleep
5-16
into a flag register. For example, this instruction is useful to
implement the recursive program, which uses the alter-
nate bank to save a register for the first time, and saves
registers into memory thereafter.
Mode Test instructions reports the current mode of opera-
tion, Native/Extended, Word/Long Word, Locked or not.
This instruction can be used to switch procedures de-
pending on the mode of operation.
Load Accumulator from R or I Register instructions are
used to report current interrupt mask status. Load from/to
register instructions are used to initialize the I register.
Load Control register instructions are used to read/write
the Status Register, set/reset control bit instructions and to
set/reset the control bits in the SR.
The No Operation instruction does nothing, and can be
used as a filler, for debugging purposes, or for timing
adjustment.
Table 5-16. CPU Control Group
Format
BTEST
DI [mask]
EI [mask]
HALT
IM p
LD A,src
LD dst,A
LD[W] HL,I
LD[W] HL,I
LDCTL dst,src
MTEST
NOP
RETI
RETN
RESC dst
SETC dst
SLP
dst=LCK, LW
dst=LCK, LW, XM
