ZiLOG Z80380 User Manual page 265

Z
ILOG
Table E-5. Valid with DDIR IW in Exteded mode. LW
bit status does not affect the operation
ADD HL,(12345678H)
ADD SP,12345678H
CALL 12345678H
CALL C,12345678H
CALL M,12345678H
CALL NC,12345678H
CALL NZ,12345678H
CALL P,12345678H
CALL PE,12345678H
CALL PO,12345678H
CALL Z,12345678H
JP 12345678H
JP C,12345678H
JP M,12345678H
JP NC,12345678H
JP NS,12345678H
JP NV,12345678H
JP NZ,12345678H
JP P,12345678H
JP PE,12345678H
JP PO,12345678H
JP S,12345678H
JP V,12345678H
JP Z,12345678H
SUB HL,(12345678H)
SUB SP,12345678H
ED C6 78 56 34 12
ED 82 78 56 34 12
CD 78 56 34 12
DC 78 56 34 12
FC 78 56 34 12
D4 78 56 34 12
C4 78 56 34 12
F4 78 56 34 12
EC 78 56 34 12
E4 78 56 34 12
CC 78 56 34 12
C3 78 56 34 12
DA 78 56 34 12
FA 78 56 34 12
D2 78 56 34 12
F2 78 56 34 12
E2 78 56 34 12
C2 78 56 34 12
F2 78 56 34 12
EA 78 56 34 12
E2 78 56 34 12
FA 78 56 34 12
EA 78 56 34 12
CA 78 56 34 12
ED D6 78 56 34 12
ED 92 78 56 34 12
Table E-6. Valid with DDIR IW. XM bit status does
not affect the operation. Transfer size
determined by LW bit
LD (12345678H),BC
LD (12345678H),DE
LD (12345678H),HL
LD (12345678H),HL
LD (12345678H),IX
LD (12345678H),IY
LD (12345678H),SP
LD (IX+123456H),BC
LD (IX+123456H),DE
LD (IX+123456H),HL
LD (IX+123456H),IY
LD (IY+123456H),BC
LD (IY+123456H),E
LD (IY+123456H),HL
LD (IY+123456H),IX
LD (SP+123456H),BC
LD (SP+123456H),DE
LD (SP+123456H),HL
LD (SP+123456H),IX
LD (SP+123456H),IY
LD BC,(12345678H)
LD BC,(IX+123456H)
LD BC,(IY+123456H)
LD BC,(SP+123456H)
LD DE,(12345678H)
LD DE,(IX+123456H)
LD DE,(IY+123456H)
LD DE,(SP+123456H)
LD HL,(12345678H)
LD HL,(12345678H)
LD HL,(IX+123456H)
LD HL,(IY+123456H)
LD HL,(SP+123456H)
LD IX,(12345678H)
LD IX,(IY+123456H)
LD IX,(SP+123456H)
LD IY,(12345678H)
LD IY,(IX+123456H)
LD IY,(SP+123456H)
LD SP,(12345678H)
LDW (BC),12345678H
LDW (DE),12345678H
LDW (HL),12345678H
U ' M
SER S ANUAL
ED 43 78 56 34 12
ED 53 78 56 34 12
22 78 56 34 12
ED 63 78 56 34 12
DD 22 78 56 34 12
FD 22 78 56 34 12
ED 73 78 56 34 12
DD CB 56 34 12 0B
DD CB 56 34 12 1B
DD CB 56 34 12 3B
DD CB 56 34 12 2B
FD CB 56 34 12 0B
FD 73 56 34 12
FD CB 56 34 12 3B
FD CB 56 34 12 2B
DD CB 56 34 12 09
DD CB 56 34 12 19
DD CB 56 34 12 39
DD CB 56 34 12 29
FD CB 56 34 12 29
ED 4B 78 56 34 12
DD CB 34 12 03
FD CB 34 12 03
DD CB 34 12 01
ED 5B 78 56 34 12
DD CB 56 34 12 13
FD CB 56 34 12 13
DD CB 56 34 12 11
2A 78 56 34 12
ED 6B 78 56 34 12
DD CB 56 34 12 33
FD CB 56 34 12 33
DD CB 56 34 12 31
DD 2A 78 56 34 12
FD CB 56 34 12 23
DD CB 56 34 12 21
FD 2A 78 56 34 12
DD CB 56 34 12 23
FD CB 56 34 12 21
ED 7B 78 56 34 12
ED 06 78 56 34 12
ED 16 78 56 34 12
ED 36 78 56 34 12
