5.5.9 External Input/Output Instruction Group (Continued)
Instruction Name
Input
Input Accumulator
Input to Word-Wide Register
Input Byte from Absolute Address
Input Word from Absolute Address
Input and Decrement (Byte)
Input and Decrement (Word)
Input, Decrement, and Repeat (Byte)
Input, Decrement, and Repeat (Word)
Input and Increment (Byte)
Input and Increment (Word)
Input, Increment, and Repeat (Byte)
Input, Increment, and Repeat (Word)
Output
Output Accumulator
Output from Word-Wide Register
Output Byte from Absolute Address
Output Word from Absolute Address
Output and Decrement (Byte)
Output and Decrement (Word)
Output, Decrement, and Repeat (Byte)
Output, Decrement, and Repeat (Word)
Output and Increment (Byte)
Output and Increment (Word)
Output, Increment, and Repeat (Byte)
Output, Increment, and Repeat (Word)
5-14
Table 5-14. External I/O Group Instructions.
Format
IN dst,(C)
IN A,(n)
INW dst,(C)
INAW A,(nn)
INAW HL,(nn)
IND
INDW
INDR
INDRW
INI
INIW
INIR
INIRW
OUT (C),src
OUT (n),A
OUTW (C), src
OUTAW (nn),A
OUTAW (nn),HL
OUTD
OUTDW
OTDR
OTDRW
OUTI
OTIW
OTIR
OTIRW
dst=A, B, C, D, E, H or L
dst=BC, DE or HL
src = A, B, C, D, E, H, L, or n
src = BC, DE, HL, or nn
