How to Use the [Home] Screen
The [Home] screen is set as the default screen when the machine is turned on.
One icon is assigned to each function, and these icons are displayed on the [Home] screen. You can
add shortcuts to frequently used functions or Web pages to the [Home] screen. Also, you can register
widgets such as the Change Langs. Widget to it. The [Home] screen and the screen of each function may
differ depending on the optional units that are installed.
To display the [Home] screen, press [Home] (
• Do not apply strong impact or force to the screen, or it may be damaged.
To switch between screens, flick your finger to the right or left on the screen.
1
12
11
1. Logged in user icon
When user authentication is enabled, an icon is displayed that indicates that users are logged in. Press the
icon to show the names of the users that are currently logged in.
2. System message
Displays messages from the machine system and applications.
3. [Login]/[Logout]
These keys are displayed when user authentication is enabled. When you press [Login], the authentication
screen appears. If you have been already logged in to the machine, [Logout] appears. To log out of the
machine, press [Logout].
For details about how to log in and out, see page 64 "Logging In the Machine".
4. [Energy Saver]
Press to switch to Sleep mode.
For details about the modes, see "Saving Energy", Getting Started.
5. Application list icon
Press to display the application list. You can create shortcuts to the applications on the [Home] screen.
) at the bottom of the screen in the center.
2
10
9
8
How to Use the [Home] Screen
4
3
5
6
7
DQC235
33
- Quick Links:
- Adding Toner
- Disposing of Used Toner
Hide quick links:
Advertisement
Table of Contents
Need help?
Do you have a question about the MP 402SPF and is the answer not in the manual?
Questions and answers
how to connect to a computer
To connect a Ricoh MP 402SPF to a computer, follow these steps:
1. Network Connection (Using Ethernet)
- Insert one end of the Ethernet cable into the printer’s Ethernet port.
- Insert the other end into the computer or network router.
- Plug the power cord into a wall socket and turn on the printer.
- Wait for the printer to recognize the network connection (this may take up to a minute).
2. Driver Installation (Using a CD-ROM)
- Insert the provided CD-ROM into the computer’s CD drive.
- Open File Explorer and double-click the CD-ROM drive.
- Run "Setup.exe" to start the installation process.
- Follow the on-screen instructions to install the printer driver.
3. Network Quick Install (For Network Setup)
- Open the installer and click [Network Quick Install].
- Accept the software license agreement and click [Next].
- Select the machine model (Ricoh MP 402SPF) from the list.
- Click [Install] to complete the setup.
4. Confirm Computer Information (If Needed for Scanning or Network Setup)
- Open Command Prompt and type `ipconfig/all` to find the computer’s name and IP address.
- Type `set user` to confirm the user name.
After completing these steps, the Ricoh MP 402SPF should be connected and ready for use.
This answer is automatically generated
