5. Print
This chapter describes frequently used printer functions and operations. For information not included in
this chapter, see Print available on our website.
Quick Install
You can install the printer drivers easily from the CD-ROM provided with this machine.
• Manage Printers permission is required to install the drivers. Log on as an Administrators group
member.
• If the [User Account Control] dialog box appears during the driver installation procedure, click
[Yes] or [Continue].
• If the [Windows Security] dialog box appears during the driver installation procedure, click [Install
this driver software anyway].
• A message appears if there is a newer version of the printer driver already installed. If there is, you
cannot install the printer driver using Auto Run. If you still want to install the printer driver, use [Add
Printer]. see "Messages Displayed When Installing the Printer Drive", Driver Installation Guide.
• The [AutoPlay] dialog box is displayed only for a few seconds under Windows 8/8.1/10 and
Windows Server 2012/2012 R2. If the [AutoPlay] dialog box disappears, use the following
procedure to replay the CD-ROM:
• Windows 8, Windows Server 2012
1. On the Charm Bar, click [Search], and then click [Computer].
2. Double-click the CD-ROM drive in which the provided CD-ROM is set, and then click
"Setup.exe".
• Windows 8.1, Windows Server 2012 R2
1. On the desktop, right-click the [Start] button, and then click [File Explorer].
2. Double-click the CD-ROM drive in which the provided CD-ROM is set, and then click
"Setup.exe".
• Windows 10
1. On the desktop, right-click the [Start] button, and then click [File Explorer].
2. Double-click the CD-ROM drive in which the provided CD-ROM is set, and then double-
click "Setup.exe".
89
- Quick Links:
- Adding Toner
- Disposing of Used Toner
Hide quick links:
Advertisement
Table of Contents
Need help?
Do you have a question about the MP 402SPF and is the answer not in the manual?
Questions and answers
how to connect to a computer
To connect a Ricoh MP 402SPF to a computer, follow these steps:
1. Network Connection (Using Ethernet)
- Insert one end of the Ethernet cable into the printer’s Ethernet port.
- Insert the other end into the computer or network router.
- Plug the power cord into a wall socket and turn on the printer.
- Wait for the printer to recognize the network connection (this may take up to a minute).
2. Driver Installation (Using a CD-ROM)
- Insert the provided CD-ROM into the computer’s CD drive.
- Open File Explorer and double-click the CD-ROM drive.
- Run "Setup.exe" to start the installation process.
- Follow the on-screen instructions to install the printer driver.
3. Network Quick Install (For Network Setup)
- Open the installer and click [Network Quick Install].
- Accept the software license agreement and click [Next].
- Select the machine model (Ricoh MP 402SPF) from the list.
- Click [Install] to complete the setup.
4. Confirm Computer Information (If Needed for Scanning or Network Setup)
- Open Command Prompt and type `ipconfig/all` to find the computer’s name and IP address.
- Type `set user` to confirm the user name.
After completing these steps, the Ricoh MP 402SPF should be connected and ready for use.
This answer is automatically generated
